Landini 9880HC
Type: High-clearance Tractors
Contents:
Production | |
| Manufacturer: | Landini |
| Type: | High-Clearance tractor |
Variants | |
| utility | |
| high-crop |
Landini 9880HC Power | |
| Engine: | 93 hp 69.4 kW |
| PTO (claimed): | 84 hp 62.6 kW |
Mechanical | |
| Chassis: | 4x2 2WD |
| 4x4 MFWD 4WD | |
| Steering: | power |
| Brakes: | hydraulic wet disc |
| Trailer brakes: | hydraulic*Optional |
| pneumatic*Optional | |
| Cab: | Cab standard with available air-conditioning. |
| Transmissions: | 12-speed synchromesh shuttle |
| 24-speed creeper | |
Hydraulics | |
| Pump flow: | 11.7 gpm 44.3 lpm |
Tractor hitch | |
| Rear Type: | II |
| Control: | position and draft control |
| Rear lift: | 9590 lbs 4350 kg |
Power Take-off (PTO) | |
| Rear PTO: | independent |
| Rear RPM: | 540/1000 (1.375) |
| Engine RPM: | 540@1967 1000@1954 |
Electrical | |
| Charging system: | alternator |
| Charging amps: | 45 |
| Battery volts: | 12 |
Engine Detail | |
| Perkins AT.4-236 | |
| turbocharged diesel | |
| 4-cylinder | |
| liquid-cooled | |
| Displacement: | 235.5 ci 3.9 L |
| Bore/Stroke: | 3.875x5.00 inches 98 x 127 mm |
| Power: | 93 hp 69.4 kW |
| Air cleaner: | dry |
| Compression: | 15.1:1 |
| Rated RPM: | 2200 |
| Starter: | electric |
| Starter volts: | 12 |
Dimensions | |
| 2WD Wheelbase: | 88.4 inches 224 cm |
| 4WD Wheelbase: | 87.4 inches 221 cm |
| 2WD Length: | 153 inches 388 cm |
| 4WD Length: | 159.8 inches 405 cm |
| 2WD Width: | 77.2 inches 196 cm |
| 4WD Width: | 79.3 inches 201 cm |
| Height (cab): | 113.4 inches 288 cm |
| 2WD Weight: | 7926 lbs 3595 kg |
| 4WD Weight: | 8951 lbs 4060 kg |
| Ground clearance: | 17.9 inches 45 cm |
| 2WD Clearance (front axle): | 29.2 inches 74 cm |
| 4WD Clearance (front axle): | 24.6 inches 62 cm |
| 2WD Front tread: | 63.4 to 80.9 inches 161 to 205 cm |
| 4WD Front tread: | 65.6 to 85.2 inches 166 to 216 cm |
| Rear tread: | 59.1 to 89.1 inches 150 to 226 cm |
