Landini 9880

Production: 1987 - 2000

Production
Manufacturer:	Landini
Type:	Utility tractor

Variants

utility

high-crop

Landini 9880 Power
Engine:	93 hp 69.4 kW

Mechanical
Chassis:	4x2 2WD
4x4 MFWD 4WD
Differential lock:	hydraulic front and rear
Steering:	power
Brakes:	hydraulic wet disc
Trailer brakes:	hydraulic*Optional
pneumatic*Optional
Cab:	Cab standard with available air-conditioning.
Transmissions:	12-speed synchromesh
12-speed shuttle
24-speed synchromesh
24-speed creeper

Hydraulics
Total flow:	11.2 gpm 42.4 lpm

Tractor hitch
Rear Type:	II
Control:	position control and top-link draft sensing
Rear lift:	9590 lbs 4350 kg

Power Take-off (PTO)
Rear PTO:	independent
Rear RPM:	540/1000 (1.375)
540/750*Optional
Engine RPM:	540@1944 1000@1917 750@1934

Electrical
Charging system:	alternator

Engine Detail
Perkins AT4.236
turbocharged diesel
4-cylinder
liquid-cooled
Displacement:	235.5 ci 3.9 L
Bore/Stroke:	3.875x5.00 inches 98 x 127 mm
Power:	93 hp 69.4 kW
Air cleaner:	dry
Compression:	15.1:1
Rated RPM:	2200
Torque:	255.9 lb-ft 347.0 Nm
Torque RPM:	1400

Dimensions
2WD Wheelbase:	97 inches 246 cm
4WD Wheelbase:	96 inches 243 cm
Length:	152.4 inches 387 cm
Width:	70.5 inches 179 cm
Height (cab):	104.1 inches 264 cm
2WD Weight:	8378 lbs 3800 kg
4WD Weight:	8818 lbs 3999 kg
4WD Clearance (front axle):	18 inches 45 cm
