Iseki TG6375

Production: 2019

Production
Manufacturer:	Iseki

Iseki TG6375 Power
Engine (gross):	35.7 hp 26.6 kW
Engine (net):	34.7 hp 25.9 kW

Mechanical
Chassis:	4x4 MFWD 4WD
Differential lock:	mechanical rear
Steering:	power
Brakes:	wet disc
Cab:	Two-post folding ROPS. Cab available with air-conditioning.
Transmissions:	24-speed
12-speed

Hydraulics
Valves:	2
Pump flow:	12.6 gpm 47.7 lpm

Tractor hitch
Rear Type:	I
Control:	position control
Rear lift (at ends):	2800 lbs 1270 kg
Rear lift (at 24"/610mm):	2535 lbs 1149 kg

Power Take-off (PTO)
Rear PTO:	independent
Rear RPM:	540/540E/1000
Mid PTO:	independent
Mid RPM:	1000/1500/2000

Electrical
Ground:	negative
Battery volts:	12

Engine Detail
Iseki E3CG
diesel
3-cylinder
liquid-cooled
Displacement:	100.5 ci 1.6 L
Bore/Stroke:	3.43x3.62 inches 87 x 92 mm
Power (gross):	35.7 hp 26.6 kW
Rated RPM:	2600
Torque:	81.9 lb-ft 111.1 Nm
Torque RPM:	1500
Starter:	electric
Starter volts:	12

Dimensions
Wheelbase:	67.7 inches 171 cm
Length:	123.2 inches 312 cm
Width:	56.9 inches 144 cm
Height (ROPS):	101.8 inches 258 cm
Height (cab):	90.2 inches 229 cm
Cab Weight:	3825 lbs 1735 kg
ROPS Weight:	3428 lbs 1554 kg
Ground clearance:	13.4 inches 34 cm
