Minneapolis-Moline Jet Star
Type: Utility Tractors
Contents:
Production | |
| Manufacturer: | Minneapolis-Moline |
| Type: | Utility tractor |
| Original price: | $5000 (1970) |
Minneapolis-Moline Jet Star Power | |
| PTO (claimed): | 44 hp 32.8 kW |
Mechanical | |
| Chassis: | 4x2 2WD |
| Cab: | Open operator station. |
| Transmissions: | 10-speed partial power shift |
| 5-speed gear | |
Tractor hitch | |
| Rear Type: | II |
Power Take-off (PTO) | |
| Rear PTO: | independent |
| Rear RPM: | 540 |
Jet Star Serial Numbers | |
| Location: | Serial number plate on the left side of the Minneapolis-Moline Jet Star tractor frame, near the brake pedals. |
| 1959: | 16500001 (gasoline) |
| 1960: | 16500285 (gasoline) |
| 1961: | 16500835 (gasoline) |
| 1962: | 16501702 (gasoline) |
| Final: | 16502439 (gasoline) |
| 1960: | 17500001 (diesel) |
| 1961: | 1750061 (diesel) |
| 1962: | 17500136 (diesel) |
| Final: | 17500196 (diesel) |
Engine Detail | |
| Minneapolis-Moline 206L-4 | |
| gasoline | |
| 4-cylinder | |
| liquid-cooled | |
| Displacement: | 206 ci 3.4 L |
| Bore/Stroke: | 3.625x5.00 inches 92 x 127 mm |
Dimensions | |
| Weight: | 4600 lbs 2086 kg |
