International Harvester D-514

Production: 1963 - 1965

Production
Manufacturer:	International Harvester
Type:	Utility tractor
Factory:	Neuss, Germany
Total built:	1199

International Harvester D-514 Power
Engine:	53 hp 39.5 kW

Mechanical
Chassis:	4x2 2WD
Steering:	power
Cab:	Open operator station.
Transmissions:	5-speed gear
10-speed two-speed power shift

Tractor hitch
Rear Type:	II/I

Power Take-off (PTO)
Rear RPM:	540 (1.375)

Engine Detail
International Harvester DD-188
diesel
4-cylinder
liquid-cooled
Displacement:	188 ci 3.1 L
Bore/Stroke:	3.689x4.39 inches 94 x 112 mm
Power:	53 hp 39.5 kW
Rated RPM:	2100
Starter type:	electric
Oil capacity:	5 qts 4.7 L
Coolant capacity:	18 qts 17.0 L

Dimensions
Wheelbase:	73.1 inches 185 cm
Length:	123.2 inches 312 cm
Width:	71.7 inches 182 cm
Height:	68 inches 172 cm
Weight:	5556 lbs 2520 kg
Ground clearance:	15.75 inches 40 cm
Front tread:	54 to 73.2 inches 137 to 185 cm
Rear tread:	54 to 73.2 inches 137 to 185 cm
