White 185
Type: Row-crop Tractors
Contents:
Production | |
| Manufacturer: | White |
| Type: | Row-Crop tractor |
| Factory: | Coldwater, Ohio, USA |
| Original price: | $61,000 (1989 ) |
White 185 Power | |
| PTO (claimed): | 185 hp 138.0 kW |
| Drawbar (tested): | 163.56 hp 122.0 kW |
| PTO (tested): | 187.55 hp 139.9 kW |
Mechanical | |
| Chassis: | 4x2 2WD |
| 4x4 MFWD 4WD | |
| Final drives: | planetary |
| Differential lock: | hydraulic rear |
| Steering: | power |
| Brakes: | independent hydraulic wet disc |
| Cab: | Cab standard with air-conditioning. Optional radio, cassette, and 8-track. |
| Transmission: | 18-speed partial powershift |
Capacity | |
| Fuel: | 74 gal 280.1 L |
| Hydraulic system: | 23 gal 87.1 L |
Hydraulics | |
| Type: | closed center pressure compensated |
| Capacity: | 23 gal 87.1 L |
| Pressure: | 2250 psi 155.1 bar |
| Valves: | 2 or 3 |
| Pump flow: | 22 gpm 83.3 lpm |
Tractor hitch | |
| Rear Type: | III/II |
| Control: | position and draft control |
| Rear lift: | 7035 lbs 3191 kg |
Power Take-off (PTO) | |
| Rear PTO: | independent |
| Clutch: | hydraulic wet disc |
| Rear RPM: | 1000 |
185 Serial Numbers | |
| Location: | Left side of frame, near step |
| 1986: | 400659 (Field Boss 185) |
| 1987: | 400887 (Field Boss 185) |
| 1987: | 400881 (185) |
| 1988: | 401579 (185) |
| 1989: | 402761 (185) |
Electrical | |
| Ground: | negative |
| Charging system: | alternator |
| Charging amps: | 62 |
| Batteries: | 2 |
| Battery volts: | 12 |
Engine Detail | |
| CDC-Cummins | |
| turbocharged diesel | |
| 6-cylinder | |
| liquid-cooled inline | |
| Displacement: | 504.5 ci 8.3 L |
| Bore/Stroke: | 4.49x5.32 inches 114 x 135 mm |
| Fuel system: | direct injection |
| Air cleaner: | dual paper elements |
| Compression: | 16.5:1 |
| Rated RPM: | 2200 |
| Starter volts: | 12 |
| Oil capacity: | 23.5 qts 22.2 L |
| Coolant capacity: | 26.6 qts 25.2 L |
Transmission | |
| Transmission: | 3x6 Over/Under |
| Type: | partial powershift |
| Gears: | 18 forward and 6 reverse |
| Clutch: | 355.6mm dry discs |
| Six forward and two reverse gears with an over and under powershift for each gear. | |
Dimensions | |
| 2WD Wheelbase: | 112 inches 284 cm |
| 4WD Wheelbase: | 90 inches 228 cm |
| Length: | 168 inches 426 cm |
| Width: | 98 inches 248 cm |
| 115 inches 292 cm (long axle) | |
| 2WD Height: | 120 inches 304 cm |
| 4WD Height: | 122 inches 309 cm |
| 2WD Clearance (front axle): | 23 inches 58 cm |
| 4WD Clearance (front axle): | 17 inches 43 cm |
| Clearance (rear axle): | 28.7 inches 72 cm |
| Clearance (drawbar): | 16.7 inches 42 cm |
| Rear axle: | Bar: 3.75 by 96 inches 95 by 2438 mm |
| Rear axle: | Bar: 3.75 by 115 inches 95 by 2921 mm |
| 2WD Front tread: | 60 to 80 inches 152 to 203 cm |
| 4WD Front tread: | 61 to 87 inches 154 to 220 cm |
| Rear tread: | 65 to 106 inches 165 to 269 cm |
| Rear tread: | 65 to 126 inches 165 to 320 cm |
