International Harvester 743

Production: 1981 - 1985

Contents:

Production

Manufacturer:International Harvester
Factory:Neuss, Germany

International Harvester 743 Power

Engine:67 hp 50.0 kW

Mechanical

Chassis:4x2 2WD
4x4 MFWD 4WD
Transmissions:8-speed
16-speed

Hydraulics

Pump flow:7.9 gpm 29.9 lpm

Tractor hitch

Rear lift:6945 lbs 3150 kg

Power Take-off (PTO)

Rear RPM:540

Engine Detail

International Harvester D-329
diesel
4-cylinder
liquid-cooled
Displacement:238.65 ci 3.9 L
Bore/Stroke:3.875x5.06 inches 98 x 129 mm
Power:67 hp 50.0 kW
Rated RPM:2300

Dimensions

Wheelbase:87.80 inches 223 cm
Length:148.82 inches 378 cm
Height:103.15 inches 262 cm
