Deutz-Allis 7145
Type: Row-crop Tractors
Contents:
Production | |
| Manufacturer: | Deutz-Allis |
| Type: | Row-Crop tractor |
Deutz-Allis 7145 Power | |
| PTO (claimed): | 144 hp 107.4 kW |
| Drawbar (tested): | 126.60 hp 94.4 kW |
| PTO (tested): | 144.56 hp 107.8 kW |
Mechanical | |
| Chassis: | 4x2 2WD |
| 4x4 MFWD 4WD | |
| Differential lock: | push-button rear |
| OPTICTRAC automatic front | |
| Steering: | hydrostatic power |
| Brakes: | hydraulic wet disc |
| Cab: | Detuz-Allis MasterCab standard with heat, air-conditioning, and air-suspension seat. Agrotronic instrumentation standard, optional Agrotronic II. |
| Transmission: | 36-speed synchronized with partial power shift |
Capacity | |
| Fuel: | 66 gal 249.8 L |
| Hydraulic system: | 10 gal 37.9 L |
Hydraulics | |
| Type: | open center |
| Capacity: | 10 gal 37.9 L |
| Pressure: | 2538 psi 175.0 bar |
| Valves: | 1 to 3 |
| Pump flow: | 18.2 gpm 68.9 lpm |
| Total flow: | 27.3 gpm 103.3 lpm |
| Steering flow: | 9.7 gpm 36.7 lpm |
Tractor hitch | |
| Rear Type: | III |
| Front Hitch: | optional |
Power Take-off (PTO) | |
| Rear PTO: | independent |
| Rear RPM: | 540/1000 |
| Front PTO: | optional |
Electrical | |
| Charging system: | alternator |
| Charging amps: | 90 |
| Charging volts: | 14 |
| Batteries: | 2 |
| Battery volts: | 6 |
Engine Detail | |
| Deutz BF6L913 | |
| turbocharged diesel | |
| 6-cylinder | |
| air-cooled | |
| Displacement: | 374 ci 6.1 L |
| Bore/Stroke: | 4.02x4.92 inches 102 x 125 mm |
| Rated RPM: | 2400 |
| Starter volts: | 12 |
| Starter power: | 5 hp 3.7 kW |
| Oil capacity: | 17 qts 16.1 L |
Transmission | |
| Transmission: | POWERMATIC |
| Type: | synchronized with partial power shift |
| Gears: | 36 forward and 12 reverse |
| Oil capacity: | 80 qts 75.7 L |
Dimensions | |
| Wheelbase: | 103.5 inches 262 cm (2WD) |
| 111.3 inches 282 cm (4WD) | |
| Length: | 185.4 inches 470 cm (2WD) |
| 187.8 inches 477 cm (4WD) | |
| Width: | 93 inches 236 cm |
