Deere 2541
Type: Utility Tractors
Contents:
Production | |
| Manufacturer: | John Deere |
| Type: | Utility tractor |
| Factory: | Nigel, South Africa |
John Deere 2541 Power | |
| Engine: | 84.5 hp 63.0 kW |
Mechanical | |
| Chassis: | 4x2 2WD |
| 4x4 MFWD 4WD | |
| Steering: | hydrostatic power |
| Cab: | Open operator station. |
| Transmission: | 8-speed |
Power Take-off (PTO) | |
| Rear RPM: | 540/1000 |
2541 Serial Numbers | |
| Location: | Serial number plate on the right side of the 2541 tractor frame, above the front axle. |
Electrical | |
| Ground: | negative |
| Charging system: | alternator |
| Battery volts: | 12 |
Engine Detail | |
| ADE | |
| turbocharged diesel | |
| 4-cylinder | |
| liquid-cooled | |
| Displacement: | 235.6 ci 3.9 L |
| Bore/Stroke: | 3.875x5.00 inches 98 x 127 mm |
| Power: | 84.5 hp 63.0 kW |
| Rated RPM: | 2300 |
| Starter volts: | 12 |
Transmission | |
| Gears: | 8 forward and 4 reverse |
Dimensions | |
| Shiping weight: | 6600 lbs 2993 kg (4WD) |
