John Deere 6600
Type: Row-crop Tractors
Contents:
Production | |
| Manufacturer: | John Deere |
| Type: | Row-Crop tractor |
| Factory: | Mannheim, Baden-Württemberg, Germany |
John Deere 6600 Power | |
| Engine: | 110 hp 82.0 kW |
Mechanical | |
| Chassis: | 4x4 MFWD 4WD |
| Differential lock: | electro-hydraulic |
| Steering: | power |
| Brakes: | wet disc |
| Cab: | Cab standard with air-conditioning. |
| Transmissions: | 20-speed partial power shift |
| 16-speed | |
| 24-speed | |
Hydraulics | |
| Type: | closed center |
| Pressure: | 2900 psi 200.0 bar |
| Pump flow: | 15.9 gpm 60.2 lpm |
| 25.4 gpm 96.1 lpm *Optional | |
Tractor hitch | |
| Rear Type: | II/IIIN |
| Rear lift: | 13620 lbs 6178 kg |
Power Take-off (PTO) | |
| Rear PTO: | independent |
| Clutch: | electro-hydraulic wet disc |
| Rear RPM: | 540/1000 |
| 540/540E/1000 | |
| Engine RPM: | 540@2017 540E@1684 1000@2208 |
| Front PTO: | independent |
Electrical | |
| Ground: | negative |
| Charging system: | alternator |
| Charging amps: | 85 |
| 120*Optional | |
| Battery CCA: | 850 |
| Battery volts: | 12 |
| Battery AH: | 174 |
Engine Detail | |
| John Deere 6068 | |
| turbocharged diesel | |
| 6-cylinder | |
| liquid-cooled | |
| Displacement: | 358.8 ci 5.9 L |
| Bore/Stroke: | 4.19x4.331 inches 106 x 110 mm |
| Power: | 110 hp 82.0 kW |
| Rated RPM: | 2100 |
| Torque: | 335.6 lb-ft 455.1 Nm |
| Torque RPM: | 1400 |
| Firing order: | 1-5-3-6-2-4 |
| Starter: | electric |
| Starter volts: | 12 |
Dimensions | |
| Wheelbase: | 104.3 inches 264 cm |
| Length: | 177.2 inches 450 cm |
| Width: | 91.3 inches 231 cm |
| Height (cab): | 110.7 inches 281 cm |
| Weight: | 10,250 lbs 4649 kg |
