Zetor Major HS 65

Production: 2017

Production
Manufacturer:	Zetor
Type:	Utility tractor

Zetor Major HS 65 Power
Engine (gross):	67 hp 50.0 kW
PTO (claimed):	61.9 hp 46.2 kW

Mechanical
Chassis:	4x4 MFWD 4WD
Steering:	power
Brakes:	wet disc
Cab:	Cab standard with air-conditioning.
Transmission:	24-speed power shuttle

Hydraulics
Type:	open center
Valves:	2
Pump flow:	10.3 gpm 39.0 lpm
Total flow:	16.1 gpm 60.9 lpm
Steering flow:	5.8 gpm 22.0 lpm

Tractor hitch
Rear Type:	II
Control:	position and draft control
Rear lift (at ends):	4270 lbs 1936 kg
Rear lift (at 24"/610mm):	3153 lbs 1430 kg

Power Take-off (PTO)
Rear PTO:	independent
Clutch:	electro-hydraulic
Rear RPM:	540/750/1000 (1.375)

Electrical
Ground:	negative
Charging system:	alternator
Charging amps:	95
Charging volts:	12
Battery volts:	12

Engine Detail
Deutz TCD 2.9 L4
turbocharged diesel
4-cylinder
liquid-cooled
Displacement:	177 ci 2.9 L
Bore/Stroke:	3.62x4.33 inches 92 x 110 mm
Emissions:	Tier IV
Power (gross):	67 hp 50.0 kW
Rated RPM:	2200
Starter:	electric
Starter volts:	12
Oil capacity:	8.5 qts 8.0 L
Coolant capacity:	10.6 qts 10.0 L

Transmission
Type:	power shuttle
Gears:	24 forward and reverse
Clutch:	dry disc
Oil capacity:	11 qts 10.4 L
Four gears in three ranges with two-speed main/creeper range shift.

Dimensions
Wheelbase:	84.6 inches 214 cm
Length:	155.6 inches 395 cm
Width:	72.4 inches 183 cm
Height (cab):	100.2 inches 254 cm
Weight:	5555 lbs 2519 kg
Ground clearance:	17.2 inches 43 cm
