Zetor Major 80

Production: 2013 - 2022

PDF

• Download Zetor MAJOR CL Operator's Manual

Production
Manufacturer:	Zetor
Type:	Utility tractor

Zetor Major 80 Power
Engine:	82 hp 61.1 kW
PTO (claimed):	74 hp 55.2 kW

Mechanical
Chassis:	4x2 2WD
4x4 MFWD 4WD
Steering:	power
Brakes:	mechanical wet disc
Trailer brakes:	pneumatic*Optional
Cab:	Cab standard with optional air-conditioning.
Transmission:	12-speed synchronized

Hydraulics
Pressure:	2611 psi 180.0 bar
Valves:	1 or 2
Total flow:	13.2 gpm 50.0 lpm

Tractor hitch
Rear Type:	II
Control:	position and draft control
Rear lift (at ends):	5845 lbs 2651 kg

Power Take-off (PTO)
Rear PTO:	independent
Clutch:	mechanical dry disc
Rear RPM:	540/1000
540/540E*Optional

Electrical
Charging system:	alternator

Engine Detail
Zetor 1105
turbocharged diesel
4-cylinder 8-valve
liquid-cooled
Displacement:	253.6 ci 4.2 L
Bore/Stroke:	4.13x4.72 inches 105 x 120 mm
Emissions:	Stage IIIA
Power:	82 hp 61.1 kW
Rated RPM:	2200
Starter type:	electric

Transmission
Type:	synchronized
Gears:	12 forward and reverse
Clutch:	280mm mechanical cerametallic disc

Dimensions
Wheelbase:	87 inches 220 cm
Length:	165.8 inches 421 cm
Width:	73.2 inches 185 cm
Height (exhaust):	104.6 inches 265 cm
4WD Weight:	6812 lbs 3089 kg
