Volvo T810

Production: 1969 - 1978

Production
Manufacturer:	Volvo
Type:	Row-Crop tractor
Factory:	Eskilstuna, Sweden
Total built:	3550
Original price:	$40,000 (1978)

Variants

2WD

4WD

Volvo T810 Power
Engine:	133 hp 99.2 kW

Mechanical
Chassis:	4x2 2WD
Differential lock:	standard
Steering:	hydrostatic power
Brakes:	disc
Cab:	Cab optional with heat
Transmission:	8-speed

Hydraulics
Type:	Trac-Trol
Pressure:	2275 psi 156.9 bar
Valves:	2
Pump flow:	7.9 gpm 29.9 lpm
11.9 gpm 45.0 lpm (optional)

Tractor hitch
Rear lift:	5,200 lbs 2358 kg
6,170 lbs 2798 kg (optional)

Power Take-off (PTO)
Rear RPM:	1000
540/1000

Engine Detail
Volvo TD50A
turbocharged diesel
6-cylinder
liquid-cooled
Displacement:	313 ci 5.1 L
Bore/Stroke:	3.750x4.724 inches 95 x 120 mm
Power:	133 hp 99.2 kW
Compression:	17:1
Rated RPM:	2300
Torque:	318 lb-ft 431.2 Nm
Torque RPM:	1650
Starter:	Bosch
Starter volts:	12
Starter power:	4 hp 3.0 kW

Transmission
Gears:	8 forward and 2 reverse

Dimensions
Wheelbase:	106 inches 269 cm
Length:	167 inches 424 cm
Width:	82 inches 208 cm
Height (cab):	102 inches 259 cm
Weight:	11,800 lbs 5352 kg
Front tread:	67 inches 170 cm
Rear tread:	63 to 71 inches 160 to 180 cm
