Massey Ferguson 5150
Contents:
Production | |
| Manufacturer: | Massey Ferguson |
| Type: | Four-wheel Drive (4WD) tractor |
| Factory: | Granadero Baigorria, Santa Fe, Argentina |
Massey Ferguson 5150 Power | |
| Engine: | 250 hp 186.4 kW |
Mechanical | |
| Chassis: | 4x4 articulated 4WD |
| Steering: | articulated power |
| Brakes: | hydraulic wet disc |
| Cab: | Cab standard with air-conditioning. |
Hydraulics | |
| Pressure: | 2276 psi 156.9 bar |
| Valves: | 4 |
| Pump flow: | 42.3 gpm 160.1 lpm |
| Steering flow: | 9.5 gpm 36.0 lpm |
Tractor hitch | |
| Rear Type: | III*Optional |
Electrical | |
| Ground: | negative |
| Batteries: | 2 |
| Battery volts: | 12 |
Engine Detail | |
| Cummins 6CT8.3 | |
| turbocharged diesel | |
| 6-cylinder | |
| liquid-cooled | |
| Displacement: | 505 ci 8.3 L |
| Bore/Stroke: | 4.49x5.31 inches 114 x 135 mm |
| Power: | 250 hp 186.4 kW |
| Rated RPM: | 2200 |
| Torque: | 723 lb-ft 980.4 Nm |
| Torque RPM: | 1500 |
| Starter: | electric |
| Starter volts: | 24 |
| Oil capacity: | 25.4 qts 24.0 L |
| Coolant capacity: | 13 qts 12.3 L |
Dimensions | |
| Wheelbase: | 124 inches 314 cm |
| Length: | 271.7 inches 690 cm |
| Width: | 129.9 inches 329 cm |
| Height: | 133.9 inches 340 cm |
| Weight: | 23810 lbs 10800 kg |
| Ground clearance: | 15.75 inches 40 cm |
