Massey Ferguson 1078
Type: Row-crop Tractors
Contents:
Production | |
| Manufacturer: | Massey Ferguson |
| Type: | Row-Crop tractor |
| Factory: | Granadero Baigorria, Santa Fe, Argentina |
Massey Ferguson 1078 Power | |
| Engine: | 75 hp 55.9 kW |
Mechanical | |
| Chassis: | 4x2 2WD |
| Steering: | power |
| Brakes: | disc |
| Cab: | Open operator station. |
| Transmission: | 8-speed gear |
Capacity | |
| Fuel: | 22.5 gal 85.2 L |
| Hydraulic system: | 9 gal 34.1 L |
Hydraulics | |
| Capacity: | 9 gal 34.1 L |
Power Take-off (PTO) | |
| Rear PTO: | independent |
| Rear RPM: | 540 (1.375) |
| Engine RPM: | 540@1680 |
Electrical | |
| Ground: | negative |
| Batteries: | 2 |
| Battery volts: | 12 |
| Battery AH: | 86 |
Engine Detail | |
| Perkins A.6-305 | |
| diesel | |
| 6-cylinder | |
| liquid-cooled | |
| Displacement: | 305 ci 5.0 L |
| Bore/Stroke: | 3.58x5.00 inches 91 x 127 mm |
| Power: | 75 hp 55.9 kW |
| Rated RPM: | 2000 |
| Starter: | electric |
| Starter volts: | 12 |
| Oil capacity: | 14.5 qts 13.7 L |
| Coolant capacity: | 15.9 qts 15.0 L |
Transmission | |
| Type: | gear |
| Gears: | 8 forward and 2 reverse |
| Clutch: | 304.8mm dry disc |
| Oil capacity: | 36 qts 34.1 L |
Dimensions | |
| Wheelbase: | 92.5 inches 234 cm |
| Length: | 144.9 inches 368 cm |
| Width: | 86.6 inches 219 cm |
| Height (steering wheel): | 70.9 inches 180 cm |
| Weight: | 10046 lbs 4556 kg |
| Ground clearance: | 21.7 inches 55 cm |
