Massey Ferguson 1095
Type: Row-crop Tractors
Contents:
Production | |
| Manufacturer: | Massey Ferguson |
| Type: | Row-Crop tractor |
| Factory: | Granadero Baigorria, Santa Fe, Argentina |
Massey Ferguson 1095 Power | |
| Engine: | 95 hp 70.8 kW |
Mechanical | |
| Chassis: | 4x2 2WD |
| Steering: | power |
| Brakes: | disc |
| Cab: | Open operator station. |
| Transmission: | 8-speed gear |
Power Take-off (PTO) | |
| Rear RPM: | 540 (1.375) |
| Engine RPM: | 540@1700 |
Electrical | |
| Ground: | negative |
| Charging system: | alternator |
| Charging amps: | 32 |
| Batteries: | 2 |
| Battery volts: | 12 |
| Battery AH: | 86 |
Engine Detail | |
| Perkins A.6-354 | |
| diesel | |
| 6-cylinder | |
| liquid-cooled | |
| Displacement: | 354 ci 5.8 L |
| Bore/Stroke: | 3.875x5.00 inches 98 x 127 mm |
| Power: | 95 hp 70.8 kW |
| Compression: | 16:1 |
| Rated RPM: | 2200 |
| Firing order: | 1-5-3-6-2-4 |
| Starter: | electric |
| Starter volts: | 12 |
Transmission | |
| Type: | gear |
| Gears: | 8 forward and 2 reverse |
| Clutch: | 304.8mm dry disc |
Dimensions | |
| Wheelbase: | 96.5 inches 245 cm |
| Length: | 143.7 inches 364 cm |
| Width: | 82.3 inches 209 cm |
| Height (steering wheel): | 70.9 inches 180 cm |
| Weight: | 11964 lbs 5426 kg |
| Ground clearance: | 21.7 inches 55 cm |
