Massey Ferguson 1030

Production: 1984 - 1991

Production
Distributor:	Massey Ferguson
Manufacturer:	Toyosha
Type:	Compact Utility tractor
Original price:	$12,000 (1991)

Variants
1030L:	industrial tow tractor

Massey Ferguson 1030 Power
Engine:	26 hp 19.4 kW
PTO (claimed):	23 hp 17.2 kW
Drawbar (tested):	18.29 hp 13.6 kW
PTO (tested):	23.35 hp 17.4 kW

Mechanical
Chassis:	4x2 2WD
4x4 MFWD 4WD
Steering:	manual (2WD)
power assist (4WD)
Brakes:	differential mechanical disc
Cab:	Open operator station. Two-post ROPS available.
Transmission:	12-speed gear

Hydraulics
Type:	open center
Pump flow:	5.4 gpm 20.4 lpm

Tractor hitch
Rear Type:	I
Rear lift (at ends):	1729 lbs 784 kg

Power Take-off (PTO)
Rear PTO:	live
Rear RPM:	540
Front PTO:	independent (optional)
Clutch:	electric

1030 Serial Numbers
1984:	00101 (2WD)
1985:	00820 (2WD)
1986:	01501 (2WD)
1987:	02542 (2WD)
1988:	03139 (2WD)
1989:	03285 (2WD)
1990:	03308 (2WD)
1991:	03686 (2WD)
1992:	03917 (2WD)
1984:	40101 (4WD)
1985:	40600 (4WD)
1986:	41245 (4WD)
1987:	42167 (4WD)
1988:	42594 (4WD)
1989:	42953 (4WD)
1990:	43251 (4WD)
1991:	43492 (4WD)
1992:	44024 (4WD)

Electrical
Ground:	negative
Battery volts:	12

Engine Detail
Toyosha MS142
diesel
3-cylinder
liquid-cooled
Displacement:	86.9 ci 1.4 L
Bore/Stroke:	3.228x3.543 inches 82 x 90 mm
Power:	26 hp 19.4 kW
Fuel system:	indirect injection
Air cleaner:	dual dry element
Pre-heating:	glow plugs
Compression:	23:1
Rated RPM:	2500
Firing order:	1-3-2
Starter volts:	12
Oil capacity:	3.7 qts 3.5 L
Coolant capacity:	4.4 qts 4.2 L

Transmission
Type:	gear
Gears:	12 forward and 3 reverse
Clutch:	215.9mm dry disc
Oil capacity:	29.6 qts 28.0 L
Four gears (1-4) plus reverse (R) in three ranges (L/M/H).

Dimensions
Wheelbase:	61.3 inches 155 cm
Length:	105.3 inches 267 cm
Width:	52.7 inches 133 cm
Height (steering wheel):	57.1 inches 145 cm (2WD)
56.3(4WD) inches 143 cm
Ground clearance:	15.7 inches 39 cm (2WD)
11.6 inches 29 cm (4WD)
