Simplicity 315
Type: Riding Lawn Mowers
Contents:
Production | |
| Manufacturer: | Simplicity (a part of Allis Chalmers) |
| Type: | Riding lawn mower |
| Factory: | Port Washington, Wisconsin, USA |
| Original price: | $475 (1972 ) |
Variants | |
| 990774: | manual start |
| 990775: | electric start |
Mechanical | |
| Chassis: | 4x2 2WD |
| Steering: | manual |
| Cab: | Open operator station. |
| Transmission: | 2-speed gear |
Capacity | |
| Fuel: | 0.75 gal 2.8 L |
Engine Detail | |
| Briggs & Stratton 130202 | |
| gasoline | |
| 1-cylinder | |
| air-cooled horizontal-shaft | |
| Displacement: | 204 cc 12.5 ci |
| Bore/Stroke: | 2.56x2.44 inches 65 x 62 mm |
| Power: | 5 hp 3.7 kW |
| Starter type: | manual recoil |
| electric*Optional | |
Transmission | |
| Type: | belt-driven gear |
| Gears: | 2 forward and 1 reverse |
Dimensions | |
| Wheelbase: | 41.5 inches 105 cm |
| Length: | 58 inches 147 cm |
| Width: | 28.25 inches 71 cm |
| Height (steering wheel): | 36.25 inches 92 cm |
| Height (hood): | 29.25 inches 74 cm |
| Shipping: | 278 lbs 126 kg |
