John Deere F710

Production: 1991 - 1997

Production
Manufacturer	John Deere
Type	Front-mount mower
Factory	Horicon, Wisconsin, USA

Mechanical
Chassis	4x2 2WD
Differential lock	mechanical front
Steering	power
Brakes	drum
Cab	Open operator station.

Power Take-off (PTO)
Front PTO	independent

Electrical
Ground	negative
Charging system	flywheel alternator
Charging amps	15
Battery volts	12

Engine Detail
Kawasaki FC540V
gasoline
1-cylinder
air-cooled vertical-shaft
Displacement	534 cc 32.6 ci
Bore/Stroke	3.50x3.38 inches 89 x 86 mm
Power	17.5 hp 13.0 kW
Air cleaner	dry
Starter	electric
Starter volts	12
Oil capacity	1.7 qts 1.6 L

Transmission
Transmission	Sundstrand
Type	belt-driven hydrostatic
Gears	infinite forward and reverse

Dimensions
Wheelbase	39.4 inches 100 cm
Length	981 inches (without deck) 2491 cm
98.75 inches (with deck) 250 cm
Height	47.6 inches 120 cm
Weight	1078 lbs 488 kg
