John Deere 325
Type: Garden Tractors
Contents:
Production | |
| Manufacturer | John Deere |
| Type | Garden tractor |
| Factory | Horicon, Wisconsin, USA |
| Original price | $6,195 (1995 ) |
Mechanical | |
| Chassis | 4x2 2WD |
| Steering | manual |
| Brakes | wet disc |
| Cab | Open operator station. Adjustable seat with 7-inches of travel. |
Tractor hitch | |
| Type | sleeve hitch OptOptional |
Power Take-off (PTO) | |
| Mid PTO | independent |
| Clutch | electric |
325 Serial Numbers | |
| 1995 | 10001 |
| 1996 | 020001 |
| 1997 | 040001 |
| 1998 | 055001 |
| 1999 | 070001 |
| 2000 | 085001 |
| 2001 | 095001 |
325 Serial Location | |
| Sear number plate on the rear of the 325, above the hitch. |
Electrical | |
| Ground | negative |
| Charging system | flywheel alternator |
| Charging amps | 13 |
| Battery CCA | 500 |
| Battery volts | 12 |
| Battery Group | 45 |
Engine Detail | |
| Kawasaki FC540V | |
| gasoline | |
| 1-cylinder | |
| air-cooled vertical-shaft | |
| The single-cylinder FC540V was used on the Deere 325 through the 1998 model year. | |
| Displacement | 534 cc 32.64 ci |
| Bore/Stroke | 3.50x3.38 inches 89 x 86 mm |
| Power | 17 hp 12.7 kW |
| Fuel system | carburetor |
| Air cleaner | dry with foam precleaner |
| Compression | 8.3:1 |
| Idle RPM | 1400-3350 |
| Starter | electric |
| Starter volts | 12 |
| Oil capacity | 1.9 qts 1.8 L |
Transmission | |
| Transmission | Tuff Torq K71A |
| Type | belt-driven hydrostatic |
| Gears | infinite forward and reverse |
| Oil capacity | 4.7 qts 4.4 L |
Dimensions | |
| Wheelbase | 47.9 inches 121 cm |
| Length | 72.25 inches 183 cm |
| 94.25 inches (with bagger) 239 cm | |
| Width | 39 inches 99 cm |
| Height | 43.6 inches 110 cm |
| Shiping weight | 642 lbs*Weight of tractor only. 291 kg |
| Front tread | 31.5 inches 80 cm |
| Rear tread | 28.5/30.75 inches 72/78 cm |
