John Deere 1435
Type: Front-mount Mowers
Contents:
Production | |
| Manufacturer | John Deere |
| Type | Front-mount mower |
| Factory | Fuquay-Varina, North Carolina, USA |
| Original price | $15,099 (2003 2WD ) |
| Original price | $17,519 (2003 4WD ) |
Mechanical | |
| Chassis | 4x2 2WD |
| 4x4 MRWD 4WD | |
| Differential lock | mechanical front |
| Steering | power |
| Brakes | disc |
| Cab | Two-post folding ROPS. |
Hydraulics | |
| Type | open center |
| Pump flow | 5.1 gpm 19.3 lpm |
Power Take-off (PTO) | |
| Front PTO | independent |
| Front RPM | 2100 |
Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 55 |
| Battery volts | 12 |
Engine Detail | |
| Yanmar 3TNE74 | |
| diesel | |
| 3-cylinder | |
| liquid-cooled horizontal-shaft inline | |
| Displacement | 1006 cc 61.4 ci |
| Bore/Stroke | 2.91x3.07 inches 74 x 78 mm |
| Power (gross) | 23.7 hp 17.7 kW |
| Fuel system | indirect injection |
| Air cleaner | dry |
| Torque | 45.5 lb-ft 61.7 Nm |
| Starter | electric |
| Starter volts | 12 |
Transmission | |
| Type | hydrostatic |
| Gears | infinite forward and reverse |
Dimensions | |
| Wheelbase | 49.2 inches 124 cm |
| Length | 86.7 inches 220 cm |
| Width | 47.6 inches 120 cm |
| Ground clearance | 6.5 inches 16 cm |
