John Deere 2210

Production: 2003 - 2006

Production
Manufacturer:	John Deere
Type:	Sub-Compact Utility tractor
Factory:	Augusta, Georgia, USA

John Deere 2210 Power
Engine (gross):	23 hp 17.2 kW
Engine (net):	22.5 hp 16.8 kW
PTO (claimed):	17.7 hp 13.2 kW

Mechanical
Chassis:	4x4 MFWD 4WD
Final drives:	spur gear
Differential lock:	mechanical rear
Steering:	power
Cab:	Two-post fixed ROPS.
Transmission:	hydrostatic

Capacity
Fuel:	5 gal 18.9 L
Hydraulic system:	3.4 gal 12.9 L

Hydraulics
Type:	open center
Capacity:	3.4 gal 12.9 L
Pressure:	1987 psi 137.0 bar
Mid valves:	2
Pump flow:	3 gpm 11.4 lpm
Total flow:	5.5 gpm 20.8 lpm
Steering flow:	2.5 gpm 9.5 lpm

Tractor hitch
Rear Type:	I*Limited
Rear lift (at 24"/610mm):	700 lbs 317 kg

Power Take-off (PTO)
Rear PTO:	independent
Clutch:	hydraulic wet disc
Rear RPM:	540
Mid PTO:	independent
Clutch:	hydraulic wet disc*Mid PTO shared clutch with rear PTO.
Mid RPM:	2100

2210 Serial Numbers
Location:	Right side of main tractor frame, above the front axle.
2003:	2100001
2004:	3100001
2005:	4310001

Electrical
Ground:	negative
Charging system:	alternator
Charging amps:	20
Battery CCA:	435
Battery volts:	12

Engine Detail
Yanmar 3TNE74
diesel
3-cylinder
liquid-cooled
Displacement:	61.4 ci 1.0 L
Bore/Stroke:	2.91x3.07 inches 74 x 78 mm
Power (gross):	23 hp 17.2 kW
Fuel system:	indirect injection
Air cleaner:	dry
Pre-heating:	coolant heater*Optional
Compression:	23.5:1
Rated RPM:	3000
Starter:	electric
Starter volts:	12
Starter power:	1.5 hp 1.1 kW
Oil capacity:	2.1 qts 2.0 L
Coolant capacity:	3.1 qts 2.9 L

Transmission
Type:	hydrostatic
Gears:	infinite (2-range) forward and reverse
Oil capacity:	13.6 qts 12.9 L

Dimensions
Wheelbase:	57 inches 144 cm
Length:	104 inches 264 cm
Width:	47.9 inches 121 cm
Height (hood):	41.8 inches 106 cm
Height (ROPS):	78.6 inches 199 cm
Clearance (front axle):	7.7 inches 19 cm
Front tread:	31.1 inches 78 cm
Rear tread:	35.3 inches 89 cm
