Ingersoll 116YT

Production: 1984 - 1990

Production
Manufacturer	Ingersoll
Type	Lawn tractor

Mechanical
Chassis	4x2 2WD
Steering	manual
Brakes	disc
Cab	Open operator station

Power Take-off (PTO)
Rear PTO	independent

116YT Serial Numbers
Location:	Serial number plate on the left side of the dashboard support frame.

Electrical
Ground	negative
Battery volts	12

Engine Detail
Briggs & Stratton 402707
gasoline
2-cylinder
air-cooled vertical-shaft horizontally-opposed
Displacement	656 cc 40.03 ci
Bore/Stroke	2.97x2.89 inches 75 x 73 mm
Power	16 hp 11.9 kW
Starter	electric
Starter volts	12

Transmission
Transmission	Peerless
Type	belt-driven gear
Gears	5 forward and 1 reverse

Dimensions
Wheelbase	42 inches 106 cm
Length	60.3 inches 153 cm
Width	33 inches 83 cm
Height (steering wheel)	39 inches 99 cm
Weight	373 lbs 169 kg
Ground clearance	6.2 inches 15 cm
