Ingersoll 1014
Type: Lawn Tractors
Contents:
Production | |
| Manufacturer | Ingersoll |
| Type | Lawn tractor |
| Factory | Winneconne, Wisconsin, USA |
| Due to failures of the friction disc drive many 1014 tractors were converted to a Peerless 800 transmission. Unsold new tractors were relabeled as model 114B. | |
Variants | |
| gear drive | |
| friction disc drive | |
| gear drive (rebuilt) | |
Mechanical | |
| Chassis | 4x2 2WD |
| Steering | manual |
| Cab | Open operator station |
Power Take-off (PTO) | |
| Rear PTO | independent |
1014 Serial Numbers | |
| Location: | Serial number plate on the left side of the dashboard support frame. |
Electrical | |
| Ground | negative |
| Battery volts | 12 |
Engine Detail | |
| Briggs & Stratton 400707 | |
| gasoline | |
| 2-cylinder | |
| air-cooled vertical-shaft horizontally-opposed | |
| Displacement | 656 cc 40.03 ci |
| Bore/Stroke | 2.97x2.89 inches 75 x 73 mm |
| Power | 14 hp 10.4 kW |
| Starter | electric |
| Starter volts | 12 |
Transmission | |
| Transmission | I-Driv |
| Type | belt-driven friction disc |
| Gears | infinite forward and reverse |
Dimensions | |
| Wheelbase | 42 inches 106 cm |
| Length | 60.3 inches 153 cm |
| Width | 33 inches 83 cm |
| Height (steering wheel) | 39 inches 99 cm |
| Ground clearance | 6.2 inches 15 cm |
