Kubota M5140
Type: Utility Tractors
Contents:
Production | |
| Manufacturer: | Kubota |
| Type: | Utility tractor |
| Original price: | $21,432 (2011) |
Variants | |
| M5140F: | 2WD ROPS sync-shuttle |
| M5140FC: | 2WD cab sync-shuttle |
| M5140DT: | 4WD ROPS sync-shuttle |
| M5140HD: | 4WD ROPS hyd-shuttle |
| M5140DTC: | 4WD cab sync-shuttle |
| M5140HDC: | 4WD cab hyd-shuttle |
Kubota M5140 Power | |
| Engine (net): | 52 hp 38.8 kW |
| PTO (claimed): | 46 hp 34.3 kW |
Mechanical | |
| Chassis: | 4x2 2WD |
| 4X4 MFWD 4WD (optional) | |
| Differential lock: | rear standard |
| Steering: | hydrostatic power |
| Brakes: | mechanical wet disc |
| Cab: | Two-post ROPS with optional canopy. Ultra Grand Cab optional with heat and air-conditioning |
| Transmissions: | 8-speed partially synchronized |
| 8-speed power shuttle | |
Capacity | |
| Fuel: | 18.5 gal 70.0 L (ROPS) |
| 23.8 gal 90.1 L (cab) | |
| Hydraulic system: | 10.6 gal 40.1 L |
| Front axle: | 8.5 qts 8.0 L |
Hydraulics | |
| Type: | open center |
| Capacity: | 10.6 gal 40.1 L |
| Valves: | 1 to 3 |
| Pump flow: | 11 gpm 41.6 lpm |
| Total flow: | 17.2 gpm 65.1 lpm |
| Steering flow: | 6.1 gpm 23.1 lpm |
Tractor hitch | |
| Rear Type: | II/I |
| Rear lift (at ends): | 4,200 lbs 1905 kg |
| Rear lift (at 24"/610mm): | 3,307 lbs 1500 kg |
Power Take-off (PTO) | |
| Rear PTO: | independent |
| Rear RPM: | 540 (1.375) |
| Engine RPM: | 540@2295 |
Electrical | |
| Ground: | negative |
| Charging system: | alternator |
| Charging amps: | 45 (ROPS) |
| 60 (cab) | |
| Battery volts: | 12 |
Engine Detail | |
| Kubota V2403-DI-T | |
| turbocharged diesel | |
| 4-cylinder | |
| liquid-cooled | |
| Displacement: | 148.5 ci 2.4 L |
| Emissions: | Interim Tier IV |
| Emission control: | EGR |
| Rated RPM: | 2600 |
| Starter: | electric |
| Starter volts: | 12 |
| Oil capacity: | 8.5 qts 8.0 L |
| Coolant capacity: | 6.6 qts 6.2 L |
Dimensions | |
| Length: | 135.6 inches 344 cm (4WD ROPS) |
| 138 inches 350 cm (4WD cab) | |
| 140.4 inches 356 cm (2WD ROPS) | |
| 142.7 inches 362 cm (2WD cab) | |
| Height (ROPS): | 82.1 inches 208 cm |
| Height (cab): | 84.4 inches 214 cm |
| Front tread: | 55.9 to 71.7 inches 141 to 182 cm (2WD) |
| Front tread: | 55.9 to 59.8 inches 141 to 151 cm (4WD) |
| Rear tread: | 52 to 67.7 inches 132 to 171 cm |
