Kubota M8540
Type: Utility Tractors
Contents:
- Download Kubota M8540 Workshop Manual
- Download Kubota M8540 Operator's Manual
- Download Kubota M8540 NARROW Operator's Manual
- Download Kubota M8540 Narrow Operator's Manual
Production | |
| Manufacturer: | Kubota |
| Type: | Utility tractor |
| Original price: | $29,955 (2011 ) |
Variants | |
| half-track tractor | |
| narrow | |
| M8540F: | 2WD ROPS sync-shuttle |
| M8540FC: | 2WD cab sync-shuttle |
| M8540DT: | 4WD ROPS sync-shuttle |
| M8540HD: | 4WD ROPS hyd-shuttle |
| M8540HD12: | 4WD ROPS 12-speed |
| M8540DTC: | 4WD cab sync-shuttle |
| M8540HDC: | 4WD cab hyd-shuttle |
| M8540HDC12: | 4WD cab 12-speed |
Kubota M8540 Power | |
| Engine: | 85.5 hp 63.8 kW |
| PTO (claimed): | 76 hp 56.7 kW |
Mechanical | |
| Chassis: | 4x2 2WD |
| 4x4 MFWD 4WD | |
| Differential lock: | rear standard |
| Steering: | hydrostatic power steering |
| Brakes: | hydraulic wet disc |
| Cab: | Two-post folding ROPS with optional canopy. Ultra Grand Cab optional with heat and air-conditioning |
| Transmissions: | 8-speed partially synchronized |
| 8-speed power shuttle | |
| 12-speed power shuttle | |
Capacity | |
| ROPS Fuel: | 23.8 gal 90.1 L |
| Cab Fuel: | 29.1 gal 110.1 L |
| Hydraulic system: | 14.25 gal 53.9 L |
| Front axle: | 10 qts 9.5 L |
Hydraulics | |
| Type: | open center |
| Capacity: | 14.25 gal 53.9 L |
| Pressure: | 2844 psi 196.1 bar |
| Valves: | 1 to 3 |
| Pump flow: | 17 gpm 64.3 lpm |
| Total flow: | 23.1 gpm 87.4 lpm |
| Steering flow: | 6.1 gpm 23.1 lpm |
Tractor hitch | |
| Rear Type: | II |
| Rear lift (at ends): | 5510 lbs 2499 kg |
| 8600 lbs 3900 kg *Optional | |
| Rear lift (at 24"/610mm): | 4630 lbs 2100 kg |
| 7275 lbs 3299 kg *Optional | |
Power Take-off (PTO) | |
| Rear PTO: | independent |
| Rear RPM: | 540 (1.375) |
| 540/1000*Optional | |
| Engine RPM: | 540@2205 |
M8540 Serial Numbers | |
| Location: | Serial number decal on the left side of the M8540 tractor frame, above the front axle. |
Electrical | |
| Ground: | negative |
| Charging amps: | 45 ROPS |
| 60 cab | |
| Battery CCA: | 900 |
| Battery volts: | 12 |
Engine Detail | |
| Kubota V3800-DI-T | |
| turbocharged diesel | |
| 4-cylinder 16-valve | |
| liquid-cooled | |
| Displacement: | 230 ci 3.8 L |
| Bore/Stroke: | 3.94x4.72 inches 100 x 120 mm |
| Emissions: | Tier III |
| Emission control: | EGR |
| Power: | 85.5 hp 63.8 kW |
| Air cleaner: | dry dual element |
| Rated RPM: | 2600 |
| Starter volts: | 12 |
| Oil capacity: | 11.3 qts 10.7 L |
| Coolant capacity: | 9.5 qts 9.0 L |
Dimensions | |
| Wheelbase: | 88.6 inches 225 cm |
| 2WD Length: | 153 inches 388 cm |
| 4WD Length: | 148 inches 375 cm |
| Width: | 78 inches 198 cm |
| Height (ROPS): | 97 inches 246 cm |
| Height (cab): | 101 inches 256 cm |
| Ground clearance: | 18.3 inches 46 cm |
| 2WD Front tread: | 56.7 to 80.3 inches 144 to 203 cm |
| 4WD Front tread: | 59.8 to 63.8 inches 151 to 162 cm |
| Rear tread: | 59.8 to 75.6 inches 151 to 192 cm |
