John Deere 4010

Production: 2002 - 2005

Production
Distributor:	John Deere
Manufacturer:	Yanmar
Type:	Compact Utility tractor
Factory:	Japan

John Deere 4010 Power
Engine (gross):	18.5 hp 13.8 kW
PTO (claimed):	14 hp 10.4 kW

Mechanical
Chassis:	4x4 MFWD 4WD
Steering:	hydrostatic power
Brakes:	wet disc
Cab:	Two-post ROPS.
Transmission:	hydrostatic

Capacity
Fuel:	3.4 gal 12.9 L
Hydraulic system:	2.6 gal 9.8 L
Front axle:	3.6 qts 3.4 L

Hydraulics
Type:	open center
Capacity:	2.6 gal 9.8 L

Tractor hitch
Rear Type:	I
Rear lift (at 24"/610mm):	860 lbs 390 kg

Power Take-off (PTO)
Rear PTO:	independent
Rear RPM:	540
Mid RPM:	2100

4010 Serial Numbers
Location:	Serial number plate on right side above the tractor's front axle.
2002:	LV4010H100001
2003:	LV4010H210001
2004:	LV4010H310001
2005:	LV4010H410001

Electrical
Ground:	negative
Charging system:	alternator
Charging amps:	20
Battery CCA:	435
Battery volts:	12

Engine Detail
Yanmar 3TNE68
diesel
3-cylinder
liquid-cooled
Displacement:	47.84 ci 0.8 L
Bore/Stroke:	2.68x2.83 inches 68 x 72 mm
Power (gross):	18.5 hp 13.8 kW
Fuel system:	indirect injection
Air cleaner:	dry
Rated RPM:	3000
Operating RPM:	1300-3225
Starter volts:	12
Oil capacity:	2.1 qts 2.0 L
Coolant capacity:	2.5 qts 2.4 L

Transmission
Type:	hydrostatic
Gears:	infinite (2-range) forward and reverse
Oil capacity:	10.4 qts 9.8 L

Dimensions
Wheelbase:	57.1 inches 145 cm
Length:	102 inches 259 cm
Width:	40.6 inches 103 cm *Minimum
44.5 inches 113 cm *Maximum
Height (hood):	44 inches 111 cm
Height (ROPS):	78.4 inches 199 cm
Weight:	1420 lbs 644 kg
Max Drawbar:	562 lbs 254 kg
Clearance (front axle):	9.8 inches 24 cm
