Production | |
Manufacturer: | John Deere |
Type: | Utility tractor |
Factory: | Mannheim, Baden-Württemberg, Germany |
John Deere 1130 Power | |
Engine (gross): | 53.6 hp 40.0 kW |
Engine (net): | 51 hp 38.0 kW |
PTO (claimed): | 42.9 hp 32.0 kW |
Mechanical | |
Chassis: | 4x2 2WD |
4x4 MFWD 4WD | |
Final drives: | planetary |
Differential lock: | mechanical rear |
Steering: | power |
Brakes: | hydraulic wet disc |
Cab: | Four-post ROPS. Cab available. |
Transmissions: | 8-speed |
16-speed two-speed power shift |
Capacity | |
Fuel: | 16.4 gal 62.1 L |
Hydraulic system: | 9.5 gal 36.0 L |
Hydraulics | |
Type: | closed center |
Capacity: | 9.5 gal 36.0 L |
Pressure: | 2248 psi 155.0 bar |
Pump flow: | 6.6 gpm 25.0 lpm |
12.4 gpm 46.9 lpm *Optional |
Tractor hitch | |
Rear Type: | II/I |
Control: | lower-link draft sensing |
Rear lift: | 4022 lbs 1824 kg |
Power Take-off (PTO) | |
Rear PTO: | independent |
Rear RPM: | 540 (1.375) |
540/1000 | |
Engine RPM: | 540@2100 |
1130 Serial Numbers | |
Location: | Serial number plate on the right side of the 1130 tractor frame, above the front axle. |
Electrical | |
Ground: | negative |
Charging system: | alternator |
Charging amps: | 28 |
Charging volts: | 14 |
Batteries: | 2 |
Battery volts: | 12 |
Battery AH: | 55 |
Engine Detail | |
John Deere | |
diesel | |
3-cylinder | |
liquid-cooled | |
Displacement: | 164 ci 2.7 L |
Bore/Stroke: | 4.02x4.33 inches 102 x 110 mm |
Power (gross): | 53.6 hp 40.0 kW |
Fuel system: | direct injection |
Air cleaner: | dry |
Compression: | 16.2:1 |
Rated RPM: | 2500 |
Idle RPM: | 650-2650 |
Operating RPM: | 1400-2500 |
Torque: | 123.2 lb-ft 167.1 Nm |
Torque RPM: | 1400 |
Starter: | electric |
Starter volts: | 12 |
Oil capacity: | 6 qts 5.7 L |
Coolant capacity: | 11 qts 10.4 L |
Dimensions | |
Wheelbase: | 81 inches 205 cm |
Length: | 133 inches 337 cm |
Width: | 73.4 inches 186 cm |
Height (ROPS): | 96.1 inches 244 cm |
Height (exhaust): | 79.1 inches 200 cm |
Shiping weight: | 4780 lbs 2168 kg |
Clearance (front axle): | 25.5 inches 64 cm |
Front tread: | 49.6 to 75.6 inches 125 to 192 cm |
Rear tread: | 53.2 to 76.8 inches 135 to 195 cm |
