Iseki TU237
Type: Compact Utility Tractors
Contents:
Production | |
| Manufacturer: | Iseki |
| Type: | Compact Utility tractor |
Variants | |
| TU237F: | 4WD |
Iseki TU237 Power | |
| Engine: | 22.7 hp 16.9 kW |
Mechanical | |
| Chassis: | 4x2 2WD |
| 4x4 MFWD 4WD | |
| Cab: | Open operator station |
| Transmission: | 12-speed |
Tractor hitch | |
| Rear Type: | JIS0 |
Power Take-off (PTO) | |
| Rear RPM: | 540 (1.375) |
| Engine RPM: | 553@2500 847@2500 1309@2500 |
Electrical | |
| Ground: | negative |
| Battery volts: | 12 |
Engine Detail | |
| Isuzu E3AG1 | |
| diesel | |
| 3-cylinder | |
| liquid-cooled | |
| Displacement: | 87.2 ci 1.4 L |
| Bore/Stroke: | 3.307x3.385 inches 84 x 86 mm |
| Power: | 22.7 hp 16.9 kW |
| Rated RPM: | 2500 |
| Starter: | electric |
| Starter volts: | 12 |
| Oil capacity: | 4.5 qts 4.3 L |
| Coolant capacity: | 7.4 qts 7.0 L |
Transmission | |
| Gears: | 12 forward and 4 reverse |
| Oil capacity: | 19 qts 18.0 L |
| Three gears, plus reverse, in four ranges. | |
Dimensions | |
| Wheelbase: | 60.2 inches 152 cm |
| Length: | 115.6 inches 293 cm |
| Width: | 47.6 inches 120 cm |
| 2WD Height: | 54.7 inches 138 cm |
| 4WD Height: | 55.5 inches 140 cm |
| 2WD Weight: | 1896 lbs 860 kg |
| 4WD Weight: | 2083 lbs 944 kg |
| 2WD Ground clearance: | 13 inches 33 cm |
| 4WD Ground clearance: | 11.8 inches 29 cm |
| 2WD Front tread: | 37/38.6 inches 93/98 cm |
| 4WD Front tread: | 41.3 inches 104 cm |
| Rear tread: | 37/43.3 inches 93/109 cm |
