Iseki TU225 Landhope

Production: 1986 - 1990

Production
Manufacturer:	Iseki
Type:	Compact Utility tractor

Variants
TU225F:	4WD

Iseki TU225 Power
Engine:	21.7 hp 16.2 kW

Mechanical
Chassis:	4x2 2WD
4x4 MFWD 4WD
Steering:	power
Cab:	Open operator station.
Transmission:	12-speed

Tractor hitch
Rear Type:	0

Power Take-off (PTO)
Rear RPM:	540 (1.375)
Engine RPM:	553@2500 847@2500 1309@2500

Electrical
Ground:	negative
Battery volts:	12

Engine Detail
Iseki E3AE1
diesel
3-cylinder
liquid-cooled
Displacement:	79.1 ci 1.3 L
Bore/Stroke:	3.15x3.386 inches 80 x 86 mm
Power:	21.7 hp 16.2 kW
Rated RPM:	2500
Starter:	electric
Starter volts:	12

Transmission
Gears:	12 forward and 4 reverse

Dimensions
Wheelbase:	60.2 inches 152 cm
Length:	114.2 inches 290 cm
Width:	47.6 inches 120 cm
2WD Height:	54.7 inches 138 cm
4WD Height:	55.5 inches 140 cm
2WD Weight:	1885 lbs 855 kg
4WD Weight:	2083 lbs 944 kg
Ground clearance:	11.8 inches 29 cm
2WD Front tread:	37/38.6 inches 93/98 cm
4WD Front tread:	41.3 inches 104 cm
Rear tread:	37/43.3 inches 93/109 cm
