Iseki TG6405

Production: 2019

Production
Manufacturer:	Iseki

Iseki TG6405 Power
Engine (gross):	38.5 hp 28.7 kW
Engine (net):	37.4 hp 27.9 kW

Mechanical
Chassis:	4x4 MFWD 4WD
Differential lock:	mechanical rear
Steering:	power
Brakes:	wet disc
Cab:	Two-post folding ROPS. Cab available with air-conditioning.
Transmission:	hydrostatic

Hydraulics
Valves:	2
Pump flow:	13.1 gpm 49.6 lpm

Tractor hitch
Rear Type:	I
Control:	position control
Rear lift (at ends):	2800 lbs 1270 kg
Rear lift (at 24"/610mm):	2535 lbs 1149 kg

Power Take-off (PTO)
Rear PTO:	independent
Rear RPM:	540/750
Mid PTO:	independent
Mid RPM:	2000

Electrical
Ground:	negative
Battery volts:	12

Engine Detail
Iseki E3CDT
diesel
3-cylinder
liquid-cooled
Displacement:	91.4 ci 1.5 L
Bore/Stroke:	3.425x3.31 inches 87 x 84 mm
Power (gross):	38.5 hp 28.7 kW
Rated RPM:	2600
Torque:	93 lb-ft 126.1 Nm
Torque RPM:	1600
Starter:	electric
Starter volts:	12

Transmission
Type:	hydrostatic
Gears:	infinite (3-range) forward and reverse

Dimensions
Wheelbase:	69.5 inches 176 cm
Length:	125 inches 317 cm
Width:	43.3 inches 109 cm
Height (ROPS):	102.4 inches 260 cm
Height (cab):	86.6 inches 219 cm
Cab Weight:	3693 lbs 1675 kg
ROPS Weight:	3307 lbs 1500 kg
Ground clearance:	10.8 inches 27 cm
