International Harvester B-414

Production: 1961 - 1966

Production
Manufacturer:	International Harvester
Type:	Utility tractor
Factory:	Bradford, England
Original price:	$2,900 (1967 )

International Harvester B-414 Power
Engine:	43.5 hp 32.4 kW
Drawbar (claimed):	31 hp 23.1 kW
PTO (claimed):	35 hp 26.1 kW
Drawbar (tested):	31.73 hp 23.7 kW
PTO (tested):	36.46 hp 27.2 kW

Mechanical
Chassis:	4x2 2WD
Steering:	manual
power optional
Brakes:	independent mechanical disc
Cab:	Open operator station.
Transmission:	8-speed

Capacity
Fuel:	12.7 gal 48.1 L
Hydraulic system:	3 gal 11.4 L

Hydraulics
Capacity:	3 gal 11.4 L
Total flow:	6.9 gpm 26.1 lpm
9.1 gpm 34.4 lpm *With power steering

Tractor hitch
Rear Type:	1

Power Take-off (PTO)
Rear PTO:	live
Rear RPM:	540

B-414 Serial Numbers
Location:	Right side of clutch/transmission housing
1961:	501 (diesel)
1962:	2575 (diesel)
1963:	14838 (diesel)
1964:	29647 (diesel)
1965:	42135 (diesel)
1966:	51664 (diesel)
1962:	501 (gasoline)
1963:	2159 (gasoline)
1964:	3995 (gasoline)
1965:	5699 (gasoline)
1966:	6345 (gasoline)

Electrical
Ground:	positive
Charging system:	generator
Charging amps:	17
Batteries:	1 (gas)
2 (diesel)
Battery volts:	12 (gas)
6 (diesel)

Engine Detail
International Harvester BC-144
gasoline
4-cylinder
liquid-cooled
Displacement:	143.1 ci 2.3 L
Bore/Stroke:	3.375x4.00 inches 86 x 102 mm
Power:	43.5 hp 32.4 kW
Air cleaner:	oil bath
Compression:	6.3:1
Rated RPM:	2000
Torque:	116 lb-ft 157.3 Nm
Torque RPM:	1300
Firing order:	1-3-4-2
Starter volts:	12
Oil capacity:	5 qts 4.7 L
Coolant capacity:	10 qts 9.5 L

Transmission
Transmission:	sliding gear
Gears:	8 forward and 2 reverse
Clutch:	dry disc
Oil capacity:	20 qts 18.9 L
Four forward gears plus reverse with high and low ranges.

Dimensions
Wheelbase:	76.5 inches 194 cm
Length:	117 inches 297 cm
Width:	64 inches 162 cm (min)
90 inches 228 cm (max)
Height (steering wheel):	60.6 inches 153 cm
Clearance (front axle):	18.7 inches 47 cm
Clearance (rear axle):	16.7 inches 42 cm
