International Harvester 833

Production: 1981 - 1990

Production
Manufacturer:	International Harvester
Type:	Utility tractor
Factory:	Neuss, Germany

Variants

utility

narrow

International Harvester 833 Power
Engine:	67 hp 50.0 kW

Mechanical
Chassis:	4x4 MFWD 4WD
Transmissions:	8-speed
16-speed
16-speed creeper

Capacity
Fuel:	17.2 gal 65.1 L
Hydraulic system:	3.2 gal 12.1 L

Hydraulics
Capacity:	3.2 gal 12.1 L
Pressure:	2538 psi 175.0 bar
Pump flow:	15.85 gpm 60.0 lpm

Tractor hitch
Rear Type:	II
Control:	position control and upper-link draft sensing
Rear lift:	4851 lbs 2200 kg

Power Take-off (PTO)
Rear PTO:	independent
Rear RPM:	540
540/1000

Electrical
Charging system:	alternator
Charging amps:	33
Battery volts:	12

Engine Detail
International Harvester D-239
diesel
4-cylinder
liquid-cooled
Displacement:	238.65 ci 3.9 L
Bore/Stroke:	3.875x5.06 inches 98 x 129 mm
Power:	67 hp 50.0 kW
Fuel system:	direct injection
Rated RPM:	2300
Torque:	173.3 lb-ft 235.0 Nm
Torque RPM:	1500
Starter volts:	12
Oil capacity:	9.5 qts 9.0 L

Dimensions
Wheelbase:	84.65 inches 215 cm
Length:	140.6 inches 357 cm
Width:	77.6 inches 197 cm
Height (cab):	97.6 inches 247 cm
Weight:	6426 lbs 2914 kg
Ground clearance:	11.9 inches 30 cm
Front tread:	54.1 to 63.9 inches 137 to 162 cm
Rear tread:	50.2 to 76 inches 127 to 193 cm
