Fiat-Hesston 580
Type: Utility Tractors
Contents:
Production | |
| Manufacturer: | Hesston (a part of Fiat) |
| Type: | Utility tractor |
| Original price: | $18,900 (1984) |
Variants | |
| 580: | 2WD |
| 580DT: | 4WD |
Hesston 580 Power | |
| PTO (claimed): | 50 hp 37.3 kW |
| Drawbar (tested): | 42.08 hp 31.4 kW |
| PTO (tested): | 51.61 hp 38.5 kW |
Mechanical | |
| Chassis: | 4x2 2WD |
| 4x4 MFWD 4WD (580DT) | |
| Steering: | hydrostatic power |
| Brakes: | differential hydraulic disc |
| Cab: | ROPS standard, cab optional. Optional radio, cassette, and CB radio. |
| Transmissions: | 8-speed partially synchronized |
| 16-speed | |
| 8-speed mechanical shuttle | |
Hydraulics | |
| Type: | open center |
| Pressure: | 2702 psi 186.3 bar |
| Valves: | 2 |
| Pump flow: | 9.6 gpm 36.3 lpm |
Tractor hitch | |
| Rear Type: | I/II |
Power Take-off (PTO) | |
| Rear PTO: | independent |
| Rear RPM: | 540 |
Electrical | |
| Charging system: | alternator |
| Charging amps: | 45 |
Engine Detail | |
| Fiat 8035 | |
| diesel | |
| 3-cylinder | |
| liquid-cooled | |
| Displacement: | 168 ci 2.8 L |
| Bore/Stroke: | 4.05x4.33 inches 103 x 110 mm |
| Compression: | 17:1 |
| Rated RPM: | 2650 |
| Starter volts: | 12 |
Dimensions | |
| Wheelbase: | 84.5 inches 214 cm (2WD) |
| 85 inches 215 cm (4WD) | |
| Length: | 130 inches 330 cm (2WD) |
| 135 inches 342 cm (4WD) | |
