Fiat 88-94

Production: 1993 - 1996

Contents:

Production

Manufacturer:Fiat

Fiat 88-94 Power

Engine:85 hp 63.4 kW

Mechanical

Chassis:4x2 2WD
4x4 MFWD 4WD optional
Transmission:24-speed

Hydraulics

Pump flow:11.8 gpm 44.7 lpm

Tractor hitch

Rear lift:9261 lbs 4200 kg

Power Take-off (PTO)

Rear RPM:540, 1000

Engine Detail

Fiat
turbocharged diesel
4-cylinder
Displacement:238.47 ci 3.9 L
Bore/Stroke:4.0945x4.53 inches 104 x 115 mm
Power:85 hp 63.4 kW
Rated RPM:2500

Transmission

Gears:24 forward and 12 reverse

Dimensions

Wheelbase:92.1 inches 233 cm
Length:144.9 inches 368 cm
Height:103.5 inches 262 cm
Weight:7,783 lbs 3530 kg
8,489 lbs 3850 kg (4WD)
