Fendt 933 Vario

Production: 2006 - 2022

Production
Manufacturer:	Fendt (a part of AGCO)
Type:	Row-Crop tractor
Factory:	Marktoberdorf, Germany

Fendt 933 Vario Power
Engine (gross):	324 hp 241.6 kW
Engine (net):	300 hp 223.7 kW
Engine (max):	333 hp 248.3 kW
PTO (claimed):	275 hp 205.1 kW

Mechanical
Chassis:	4x4 MFWD 4WD
Steering:	power
Brakes:	wet disc
Cab:	Cab standard with heat and air-conditioning.
Transmission:	continously variable transmission (CVT)

Capacity
Fuel:	174.4 gal 660.1 L
Hydraulic system:	23 gal 87.1 L

Hydraulics
Type:	load sensing
Capacity:	23 gal 87.1 L
Pressure:	2900 psi 200.0 bar
Valves:	4
Total flow:	42.3 gpm 160.1 lpm
57.1 gpm 216.1 lpm (optional)

Tractor hitch
Rear Type:	IV
Rear lift (at ends):	19,800 lbs 8981 kg
Front lift (at ends):	9,000 lbs 4082 kg

Power Take-off (PTO)
Rear PTO:	independent
Rear RPM:	540E/1000
1000
Front PTO:	optional
Front RPM:	1000

Electrical
Charging system:	alternator
Charging amps:	300*Dual 150A alternators
Battery volts:	12

Engine Detail
Deutz 2013 L06 4V
intercooled turbocharged diesel
6-cylinder 24-valve
liquid-cooled
Displacement:	435.8 ci 7.1 L
Bore/Stroke:	4.25x5.12 inches 108 x 130 mm
Rated Power (ECE R24):	300 hp 223.7 kW
Rated Power (EC 97/98):	324 hp 241.6 kW
Maximum Power (ECE R24):	330 hp 246.1 kW
Maximum Power (EC 97/68):	333 hp 248.3 kW
Rated RPM:	2200
Torque:	966.2 lb-ft 1310.2 Nm
Torque RPM:	1450

Transmission
Transmission:	Fendt Vario
Type:	continously variable transmission (CVT)
Gears:	infinite (2-range) forward and reverse

Dimensions
Wheelbase:	120.1 inches 305 cm
Length:	222.6 inches 565 cm
Width:	108.3 inches 275 cm
Height:	130.8 inches 332 cm
Ground clearance:	22.4 inches 56 cm
