Dongfeng DF-304
Type: Compact Utility Tractors
Contents:
Production | |
| Manufacturer: | Dongfeng |
| Type: | Compact Utility tractor |
| Factory: | Changzhou, Jiangsu, China |
Variants | |
| 2WD |
Dongfeng DF-304 Power | |
| Engine: | 30 hp 22.4 kW |
Mechanical | |
| Chassis: | 4x4 MFWD 4WD |
| Steering: | power |
| Brakes: | disc |
| Transmission: | 8-speed |
Hydraulics | |
| Total flow: | 6.9 gpm 26.1 lpm |
Tractor hitch | |
| Rear Type: | I |
| Rear lift (at 24"/610mm): | 1094 lbs 496 kg |
Power Take-off (PTO) | |
| Rear PTO: | live*Two-stage clutch. |
| Rear RPM: | 540/1000 |
Engine Detail | |
| ZN390T | |
| diesel | |
| 3-cylinder | |
| liquid-cooled | |
| Displacement: | 110.6 ci 1.8 L |
| Bore/Stroke: | 3.543x3.74 inches 90 x 95 mm |
| Power: | 30 hp 22.4 kW |
| Rated RPM: | 2500 |
Transmission | |
| Gears: | 8 forward and 2 reverse |
| Oil capacity: | 26.4 qts 25.0 L |
Dimensions | |
| Wheelbase: | 66.9 inches 169 cm |
| Length: | 127.4 inches 323 cm |
| Width: | 58.5 inches 148 cm |
| Height: | 60.5 inches 153 cm |
| Weight: | 2933 lbs 1330 kg |
| Ground clearance: | 14.1 inches 35 cm |
