Dongfeng DF-504
Contents:
Production | |
| Manufacturer: | Dongfeng |
| Factory: | Changzhou, Jiangsu, China |
Variants | |
| 2WD |
Dongfeng DF-504 Power | |
| Engine: | 50 hp 37.3 kW |
Mechanical | |
| Chassis: | 4x4 MFWD 4WD |
| Steering: | hydraulic power |
| Brakes: | wet disc |
| Transmission: | 12-speed |
Tractor hitch | |
| Rear Type: | II |
| Rear lift (at 24"/610mm): | 1,985 lbs 900 kg |
Power Take-off (PTO) | |
| Rear RPM: | 540/1000 |
Engine Detail | |
| JD4100T | |
| diesel | |
| 4-cylinder | |
| liquid-cooled | |
| Displacement: | 201.3 ci 3.3 L |
| Bore/Stroke: | 3.74x4.134 inches 95 x 105 mm |
| Power: | 50 hp 37.3 kW |
| Rated RPM: | 2400 |
Transmission | |
| Gears: | 12 forward and 3 reverse |
Dimensions | |
| Wheelbase: | 75.1 inches 190 cm |
| Length: | 146.7 inches 372 cm |
| Width: | 63.6 inches 161 cm |
| Height: | 85.4 inches 216 cm |
| Weight: | 4,057 lbs 1840 kg |
| Ground clearance: | 14.4 inches 36 cm |
