Deutz-Fahr DX 130
Type: Row-crop Tractors
Contents:
Production | |
| Manufacturer: | Deutz-Fahr |
| Type: | Row-Crop tractor |
Deutz-Fahr DX 130 Power | |
| PTO (claimed): | 120 hp 89.5 kW |
| Drawbar (tested): | 102.63 hp 76.5 kW |
| PTO (tested): | 121.27 hp 90.4 kW |
Mechanical | |
| Chassis: | 4x2 2WD |
| 4x4 MFWD 4WD | |
| Final drives: | planetary |
| Differential lock: | hydraulic foot-operated |
| Steering: | hydrostatic power |
| Brakes: | hydraulic disc |
| Cab: | Cab standard with air-conditioning. |
| Transmission: | 24-speed two-speed power shift |
Hydraulics | |
| Type: | open center |
| Valves: | 1 to 3 |
| Total flow: | 27 gpm 102.2 lpm |
Tractor hitch | |
| Rear Type: | III/II |
| Rear lift (at ends): | 14330 lbs 6500 kg |
Power Take-off (PTO) | |
| Rear PTO: | independent |
| Rear RPM: | 540/1000 (1.375) |
| Engine RPM: | 540@2070 1000@2070 |
Electrical | |
| Ground: | negative |
| Battery volts: | 12 |
Engine Detail | |
| Deutz BF6L 913 | |
| turbocharged diesel | |
| 6-cylinder | |
| air-cooled | |
| Displacement: | 373.9 ci 6.1 L |
| Bore/Stroke: | 4.02x4.92 inches 102 x 125 mm |
| Compression: | 15.5:1 |
| Rated RPM: | 2300 |
| Starter: | electric |
| Starter volts: | 12 |
| Oil capacity: | 16.9 qts 16.0 L |
Transmission | |
| Type: | two-speed power shift |
| Gears: | 24 forward and 8 reverse |
| Clutch: | hydraulic dry disc |
| Oil capacity: | 56 qts 53.0 L |
| Four gears (1-4) in three ranges (low, medium, high) with two-speed power shift. | |
Dimensions | |
| Wheelbase: | 108.5 inches 275 cm |
| Width: | 93.3 inches 236 cm |
| Height: | 113 inches 287 cm |
| Operating weight: | 13940 lbs 6323 kg (18.4-38 duals) |
| Ballasted weight: | 17630 lbs 7996 kg |
| Rear tread: | 63 to 86 inches 160 to 218 cm |
