Deutz-Fahr 4046E Keyline

Production: 2018

Production
Manufacturer:	Deutz-Fahr
Type:	Utility tractor

Deutz-Fahr 4046E Keyline Power
Engine:	44.3 hp 33.0 kW

Mechanical
Chassis:	4x2 2WD
4x4 MFWD 4WD
Differential lock:	mechanical
Steering:	power
Cab:	Open operator station. Two-post ROPS available.
Transmissions:	8-speed gear
12-speed creeper
8-speed partially synchronized

Hydraulics
Type:	open center
Valves:	2 to 4
Pump flow:	7.1 gpm 26.9 lpm

Tractor hitch
Rear Type:	II
Rear lift:	2756 lbs 1250 kg

Power Take-off (PTO)
Rear PTO:	independent
Rear RPM:	540
540/540E*Optional
540/1000*Optional

Electrical
Ground:	negative
Battery volts:	12

Engine Detail
Simpson SJ327E
diesel
3-cylinder
liquid-cooled
Displacement:	164.8 ci 2.7 L
Bore/Stroke:	3.74x5.00 inches 95 x 127 mm
Emissions:	Stage IIIA
Power:	44.3 hp 33.0 kW
Rated RPM:	2200
Torque:	132.8 lb-ft 180.1 Nm
Starter:	electric
Starter volts:	12

Dimensions
2WD Wheelbase:	75.6 inches 192 cm
4WD Wheelbase:	76.8 inches 195 cm
Length:	139.8 inches 355 cm
Width:	70.9 inches 180 cm
Height (steering wheel):	64.3 inches 163 cm
2WD ROPS Weight:	4630 lbs 2100 kg
4WD ROPS Weight:	5512 lbs 2500 kg
2WD Front tread:	57.6 inches 146 cm
4WD Front tread:	58.6 inches 148 cm
Rear tread:	56.7 inches 144 cm
