Deere 6605
Type: Utility Tractors
Contents:
Production | |
| Manufacturer: | John Deere |
| Type: | Utility tractor |
| Factory: | Mannheim, Baden-Württemberg, Germany |
| Original price: | $36,900 (1999 ) |
John Deere 6605 Power | |
| PTO (claimed): | 95 hp 70.8 kW |
Mechanical | |
| Chassis: | 4x2 2WD |
| 4x4 MFWD 4WD | |
| Steering: | power |
| Brakes: | hydraulic wet disc |
| Cab: | Two-post foldable ROPS. Advantage Cab optional with air-conditioning. |
| Transmissions: | 12-speed fully synchronized |
| 16-speed power shuttle | |
Hydraulics | |
| Type: | HydraVantage constant flow load sensing |
| Pressure: | 2500 psi 172.4 bar |
| Valves: | 1 |
| Total flow: | 17.5 gpm 66.2 lpm |
Tractor hitch | |
| Rear Type: | II |
| Control: | position control with optional draft control |
| Rear lift: | 5915 lbs 2683 kg |
Power Take-off (PTO) | |
| Rear PTO: | independent |
| Rear RPM: | 540/1000 |
| Engine RPM: | 540@2143 1000@2208 |
6605 Serial Numbers | |
| 1998: | 206500 |
| 1999: | 233000 |
| 2000: | 261400 |
| 2002: | 322111 |
Electrical | |
| Ground: | negative |
| Charging system: | alternator |
| Charging amps: | 90 |
| Battery CCA: | 1230 |
| Battery volts: | 12 |
| Battery AH: | 154 |
Engine Detail | |
| John Deere 6068 | |
| turbocharged diesel | |
| 6-cylinder | |
| liquid-cooled | |
| Displacement: | 414 ci 6.8 L |
| Bore/Stroke: | 4.19x5.00 inches 106 x 127 mm |
| Air cleaner: | dry dual element |
| Compression: | 17:1 |
| Rated RPM: | 2100 |
| Idle RPM: | 825-2510 |
| Operating RPM: | 1000-2300 |
| Torque: | 365 lb-ft 494.9 Nm |
| Torque RPM: | 1400 |
| Firing order: | 1-5-3-6-2-4 |
| Starter volts: | 12 |
| Starter power: | 4.6 hp 3.4 kW |
| Oil capacity: | 12.7 qts 12.0 L |
| Coolant capacity: | 13.7 qts 13.0 L |
| Cab Coolant capacity: | 16.4 qts 15.5 L |
| Intake valve clearance: | 0.014 inches 0.356 mm |
| Exhaust valve clearance: | 0.018 inches 0.457 mm |
Dimensions | |
| 2WD Wheelbase: | 104.3 inches 264 cm |
| 4WD Wheelbase: | 106.3 inches 270 cm |
| Length: | 177.2 inches 450 cm |
| Rear axle: | Flange |
| Rear axle: | Optional rack-and-pinion: 3.1 by 100.6 inches 78 by 2555 mm |
| Rear tread: | 59.7/63.5/67.6/71.3/75.4 inches 151/161/171/181/191 cm(flange) |
| Rear tread: | 61.5 to 106.3 inches 156 to 270 cm (rack-and-pinion) |
