Deere 2955
Type: Utility Tractors
Contents:
Production | |
| Manufacturer: | John Deere |
| Type: | Utility tractor |
| Factory: | Mannheim, Baden-Württemberg, Germany |
| Original price: | $39,000 (1992 ) |
Variants | |
| high-clearance |
John Deere 2955 Power | |
| Engine: | 97 hp 72.3 kW |
| Drawbar (claimed): | 74.2 hp 55.3 kW |
| PTO (claimed): | 85 hp 63.4 kW |
| Drawbar (tested): | 72.99 hp 54.4 kW |
| PTO (tested): | 86.22 hp 64.3 kW |
Mechanical | |
| Chassis: | 4x2 2WD |
| 4x4 MFWD 4WD | |
| Steering: | power |
| Brakes: | differential hydraulic wet disc |
| Cab: | Roll-Gard ROPS. Optional Sound-Gard cab. |
| Transmissions: | 8-speed partially synchronized |
| 16-speed partial power shift | |
| 12-speed | |
Capacity | |
| Fuel: | 32 gal 121.1 L |
| Hydraulic system: | 11.9 gal 45.0 L |
Hydraulics | |
| Type: | closed center |
| Capacity: | 11.9 gal 45.0 L |
| Valves: | 1 to 3 |
| Total flow: | 21 gpm 79.5 lpm |
| Steering press.: | 2320 psi 160.0 bar |
Tractor hitch | |
| Rear Type: | II |
| Rear lift: | 5,235 lbs 2374 kg |
| Front Hitch: | II*Optional |
| Front lift: | 3,372 lbs 1529 kg |
Power Take-off (PTO) | |
| Rear PTO: | independent |
| Rear RPM: | 540/1000 |
| Front PTO: | independent (optional) |
| Front RPM: | 1000 |
2955 Serial Numbers | |
| Location: | Serial number plate on the right side of the tractor frame, above the front axle. |
| 1987: | 600000 |
| 1988: | 624800 |
| 1989: | 652968 |
| 1990: | 685843 |
| 1991: | 718292 |
| 1992: | 742062 |
Electrical | |
| Ground: | negative |
| Charging system: | alternator |
| ROPS Charging amps: | 55 |
| Cab Charging amps: | 85 |
| Batteries: | 2 |
| Battery CCA: | 600 |
| Battery volts: | 12 |
Engine Detail | |
| John Deere | |
| diesel | |
| 6-cylinder | |
| liquid-cooled | |
| Displacement: | 359 ci 5.9 L |
| Bore/Stroke: | 4.19x4.33 inches 106 x 110 mm |
| Power: | 97 hp 72.3 kW |
| Air cleaner: | two paper elements |
| Compression: | 17.8:1 |
| Rated RPM: | 2300 |
| Starter volts: | 12 |
| Oil capacity: | 12.2 qts 11.5 L |
| Coolant capacity: | 18 qts 17.0 L |
Dimensions | |
| Wheelbase: | 102 inches 259 cm |
