Deere 2855N

Production: 1987 - 1992

Production
Manufacturer:	John Deere
Type:	Orchard/Vineyard tractor
Original price:	$31,000 (1992 )

John Deere 2855N Power
PTO (claimed):	80 hp 59.7 kW

Mechanical
Chassis:	4x2 2WD
4x4 MFWD 4WD
Steering:	power
Brakes:	hydraulic disc
Cab:	Open operator station.
Transmissions:	8-speed partially synchronized
16-speed partial power shift
12-speed

Hydraulics
Type:	closed center
Pressure:	2320 psi 160.0 bar
Valves:	1
Pump flow:	21 gpm 79.5 lpm

Tractor hitch
Rear Type:	II/I
Rear lift:	3100 lbs 1406 kg

Power Take-off (PTO)
Rear PTO:	independent
Clutch:	wet disc
Rear RPM:	540/1000

2855N Serial Numbers
1987:	600000
1988:	624800
1989:	652661
1990:	685906
1991:	718996
1992:	747593

Electrical
Ground:	negative
Charging system:	alternator
Charging amps:	55
Batteries:	2
Battery CCA:	400
Battery volts:	12

Engine Detail
John Deere
turbocharged diesel
4-cylinder
liquid-cooled
Displacement:	239 ci 3.9 L
Bore/Stroke:	4.19x4.33 inches 106 x 110 mm
Compression:	17.8:1
Oil capacity:	10.6 qts 10.0 L
Coolant capacity:	13.7 qts 13.0 L

Dimensions
Wheelbase:	84 inches 213 cm
Width:	65 inches 165 cm
Height:	59 inches 149 cm
Weight:	5630 lbs 2553 kg
