Deere 1450

Production: 1984 - 1988

Production
Distributor:	John Deere
Manufacturer:	Yanmar
Type:	Utility tractor
Factory:	Japan
Original price:	$17,000 (1988 )

John Deere 1450 Power
Engine (gross):	55 hp 41.0 kW
PTO (claimed):	50 hp 37.3 kW
Drawbar (tested):	43.18 hp 32.2 kW
PTO (tested):	51.39 hp 38.3 kW

Mechanical
Chassis:	4x2 2WD
4x4 MFWD 4WD
Final drives:	planetary
Differential lock:	mechanical
Steering:	power assist
Brakes:	differential hydraulic wet disc
Cab:	ROPS.
Transmission:	9-speed sliding gear

Hydraulics
Type:	open center
Valves:	0 to 2
Total flow:	10.7 gpm 40.5 lpm

Tractor hitch
Rear Type:	II/I
Control:	center link sensing with position and draft control
Rear lift (at 24"/610mm):	2,652 lbs 1202 kg

Power Take-off (PTO)
Rear PTO:	independent
Rear RPM:	540

1450 Serial Numbers
Location:	Below PTO
1984:	1000
1985:	2201
1986:	3001
1987:	3501
1988:	3530

Electrical
Ground:	negative
Charging system:	alternator
Charging amps:	25
Battery volts:	12

Engine Detail
Yanmar
diesel
4-cylinder
liquid-cooled
Displacement:	190.3 ci 3.1 L
Bore/Stroke:	3.74x4.33 inches 95 x 110 mm
Power (gross):	55 hp 41.0 kW
Compression:	18:1
Rated RPM:	2400
Starter volts:	12
Oil capacity:	12.7 qts 12.0 L
Coolant capacity:	11.1 qts 10.5 L

Transmission
Type:	sliding gear
Gears:	9 forward and 3 reverse

Dimensions
Wheelbase:	82.8 inches 210 cm
