Cub Cadet 7532
Type: Compact Utility Tractors
Contents:
Production | |
| Distributor: | Cub Cadet |
| Manufacturer: | Mitsubishi |
| Type: | Compact Utility tractor |
| Original price: | $13,800 (2007) |
Cub Cadet 7532 Power | |
| Engine: | 32 hp 23.9 kW |
| PTO (claimed): | 25.5 hp 19.0 kW |
Mechanical | |
| Chassis: | 4x4 MFWD 4WD |
| Differential lock: | standard |
| Steering: | hydrostatic power |
| Brakes: | mechanical wet disc |
| Cab: | Two-post foldable ROPS |
| Transmission: | hydrostatic |
Capacity | |
| Fuel: | 7.1 gal 26.9 L |
| Hydraulic system: | 8.2 gal 31.0 L |
| Front axle: | 4.2 qts 4.0 L |
Hydraulics | |
| Type: | gear pump |
| Capacity: | 8.2 gal 31.0 L |
| Pressure: | 2204 psi 152.0 bar |
| Pump flow: | 7.2 gpm 27.3 lpm |
| Total flow: | 10.5 gpm 39.7 lpm |
| Steering flow: | 3.3 gpm 12.5 lpm |
Tractor hitch | |
| Rear Type: | I |
| Control: | position control |
| Rear lift (at ends): | 2,646 lbs 1200 kg |
| Rear lift (at 24"/610mm): | 1,720 lbs 780 kg |
Power Take-off (PTO) | |
| Rear PTO: | independent |
| Rear RPM: | 540 (1.375) |
| Engine RPM: | 540@2376 |
| Mid PTO: | optional |
| Mid RPM: | 2000 |
Electrical | |
| Ground: | negative |
| Charging system: | alternator |
| Charging amps: | 50 |
| Charging volts: | 12 |
| Battery CCA: | 500 |
| Battery volts: | 12 |
Engine Detail | |
| Mitsubishi K3M | |
| turbocharged diesel | |
| 3-cylinder | |
| liquid-cooled | |
| Displacement: | 91.29 ci 1.5 L |
| Bore/Stroke: | 3.307x3.543 inches 84 x 90 mm |
| Power: | 32 hp 23.9 kW |
| Fuel system: | Bosch pump with DLLA 150 P injectors |
| Pre-heating: | glow plugs |
| thermostart | |
| Compression: | 18:1 |
| Rated RPM: | 2500 |
| Firing order: | 1-3-2 |
| Starter volts: | 12 |
| Coolant capacity: | 5.8 qts 5.5 L |
| Intake valve clearance: | 0.010 inches 0.254 mm (cold) |
| Exhaust valve clearance: | 0.010 inches 0.254 mm (cold) |
Transmission | |
| Type: | hydrostatic |
| Gears: | infinite (3-range) forward and reverse |
| Oil capacity: | 32.7 qts 30.9 L |
Dimensions | |
| Wheelbase: | 67.3 inches 170 cm |
| Length: | 121 inches 307 cm |
| Width: | 54 inches 137 cm |
| Height (ROPS): | 84.3 inches 214 cm |
| Weight: | 2,456 lbs 1114 kg |
| Max Drawbar: | 969 lbs 439 kg |
| Ground clearance: | 12.8 inches 32 cm |
