Fiat 780

Production: 1975 - 1984

Production
Manufacturer:	Fiat

Variants
780:	2WD
780DT:	4WD

Fiat 780 Power
Engine:	78 hp 58.2 kW

Mechanical
Chassis:	4x2 2WD
4x4 MFWD 4WD (780DT)
Final drives:	planetary
Steering:	hydrostatic power
Brakes:	hydraulic wet disc
Trailer brakes:	hydraulic*Optional
Cab:	Open operator station. Optional four-post ROPS. Optional cab with heater.
Transmissions:	8-speed
12-speed
16-speed

Hydraulics
Type:	open center
Pump flow:	6.82 gpm 25.8 lpm

Tractor hitch
Rear Type:	II
Control:	position and draft control
Rear lift:	5292 lbs 2400 kg
Rear Arms:	telecoping (optional)

Power Take-off (PTO)
Rear PTO:	independent
Rear RPM:	540 (1.375)
540/1000 (1.375)
1000 (1.75)

Electrical
Ground:	negative
Charging system:	alternator
Battery volts:	12
Battery AH:	120

Engine Detail
Fiat 8045
diesel
4-cylinder
liquid-cooled
Displacement:	223.94 ci 3.7 L
Bore/Stroke:	4.33x4.05 inches 110 x 103 mm
Power:	78 hp 58.2 kW
Fuel system:	direct injection
Compression:	17:1
Rated RPM:	2440
Operating RPM:	1000-2440
Starter volts:	12

Dimensions
2WD Wheelbase:	89 inches 226 cm
4WD Wheelbase:	89.4 inches 227 cm
Length:	142.5 inches 361 cm
Width:	73 inches 185 cm
Height (steering wheel):	70.9 inches 180 cm
2WD Weight:	6482 lbs 2940 kg
4WD Weight:	7056 lbs 3200 kg
4WD Ground clearance:	18.1 inches 45 cm
2WD Ground clearance:	20.1 inches 51 cm
Front tread:	59.1/63/66.9/70.9/76.2 inches 150/160/169/180/193 cm(4WD)
Rear tread:	55.1/59.1/63/66.9/70.9/74.8/78.7/82.7 inches 139/150/160/169/180/189/199/210 cm
