Case IH Farmall 75N

Production: 2009 - 2016

Production
Manufacturer:	Case IH
Type:	Orchard/Vineyard tractor
Original price:	$41,624 (2014 ROPS )

Case IH Farmall 75N Power
Engine (gross):	76 hp 56.7 kW
PTO (claimed):	62 hp 46.2 kW

Mechanical
Chassis:	4x2 2WD
4x4 MFWD 4WD
Final drives:	inboard planetary
Differential lock:	mechanical (2WD)
electro-hydraulic (4WD)
Steering:	hydrostatic power
Brakes:	hydraulic wet disc
Cab:	Two-post foldable mid ROPS. Cab optional with air-conditioning.
Transmissions:	16-speed mechanical shuttle
16-speed power shuttle
32-speed power shuttle

Hydraulics
Type:	open center
Rear valves:	2 or 3
Pump flow:	12.7 gpm 48.1 lpm
16.9 gpm 64.0 lpm (optional)
Total flow:	20 gpm 75.7 lpm
Steering flow:	7.2 gpm 27.3 lpm

Tractor hitch
Rear Type:	II
Control:	lower link draft sensing
Rear lift (at 24"/610mm):	4400 lbs 1995 kg

Power Take-off (PTO)
Rear PTO:	independent
Clutch:	hydraulic dry disc
Rear RPM:	540
540/1000

Electrical
Ground:	negative
Charging system:	alternator
Charging amps:	120
Battery CCA:	800
Battery volts:	12

Engine Detail
FPT
turbocharged intercooled diesel
4-cylinder
liquid-cooled
Displacement:	195 ci 3.2 L
Bore/Stroke:	3.90x4.095 inches 99 x 104 mm
Emissions:	Tier III
Power (gross):	76 hp 56.7 kW
Fuel system:	mechanical direct injection
Rated RPM:	2300
Starter:	electric
Starter volts:	12

Dimensions
2WD Wheelbase:	80.1 inches 203 cm
4WD Wheelbase:	81.1 inches 205 cm
Length:	152 inches 386 cm
Width:	52.9 inches 134 cm (min)
Ground clearance:	10.5 inches 26 cm
Rear axle:	Flange
