Case 1170

Production: 1970 - 1971

Production
Manufacturer:	J.I. Case
Type:	Row-Crop tractor
Factory:	Racine, Wisconsin, USA
Total built:	1816
Original price:	$12,700 (1970 )

J.I. Case 1170 Power
Drawbar (claimed):	110 hp 82.0 kW
PTO (claimed):	122 hp 91.0 kW
Drawbar (tested):	108.15 hp 80.6 kW
PTO (tested):	121.93 hp 90.9 kW

Mechanical
Chassis:	4x2 2WD
Steering:	power
Brakes:	hydraulic disc
Cab:	Open operator station. Cab optional.
Transmissions:	8-speed
12-speed

Hydraulics
Valves:	2
Pump flow:	16 gpm 60.6 lpm

Tractor hitch
Rear Type:	II

Power Take-off (PTO)
Rear PTO:	independent
Rear RPM:	540, 1000

Engine Detail
J.I. Case
turbocharged diesel
6-cylinder
liquid-cooled
Displacement:	451 ci 7.4 L
Bore/Stroke:	4.375x5.00 inches 111 x 127 mm
Rated RPM:	2100
Starter volts:	12
Coolant capacity:	40 qts 37.9 L

Dimensions
Weight:	12,000 lbs 5443 kg
