Kubota MX5100
Type: Utility Tractors
Contents:
Production | |
| Manufacturer: | Kubota |
| Type: | Utility tractor |
| Original price: | $16,989 (2011 ) |
Variants | |
| MX5100F: | 2WD gear |
| MX5100DT: | 4WD gear |
| MX5100HST: | 4WD hydro |
Kubota MX5100 Power | |
| Engine (gross): | 52.2 hp 38.9 kW |
| Engine (net): | 50 hp 37.3 kW |
| PTO (claimed): | 44 hp 32.8 kW (gear) |
| 42.5 hp 31.7 kW (hydro) | |
Mechanical | |
| Chassis: | 4x2 2WD |
| 4x4 MFWD 4WD (optional) | |
| Differential lock: | rear standard |
| Steering: | hydrostatic power |
| Brakes: | mechanical wet disc |
| Cab: | Two-post foldable ROPS. Optional canopy. |
| Transmissions: | 8-speed partially synchronized |
| hydrostatic | |
Capacity | |
| Fuel: | 13.2 gal 50.0 L |
| Hydraulic system: | 11.6 gal 43.9 L |
| Front axle: | 7.9 qts 7.5 L |
Hydraulics | |
| Type: | open center |
| Capacity: | 11.6 gal 43.9 L |
| Valves: | 0 to 3 |
| Pump flow: | 9.2 gpm 34.8 lpm |
| Total flow: | 14 gpm 53.0 lpm |
| Steering flow: | 4.8 gpm 18.2 lpm |
Tractor hitch | |
| Rear Type: | II/I |
| Rear lift (at ends): | 2,866 lbs 1300 kg |
| Rear lift (at 24"/610mm): | 2,310 lbs 1047 kg |
Power Take-off (PTO) | |
| Rear PTO: | independent |
| Rear RPM: | 540 (1.375) |
| Engine RPM: | 540@2700 |
Electrical | |
| Ground: | negative |
| Charging system: | alternator |
| Charging amps: | 40 |
| Battery CCA: | 582 |
| Battery volts: | 12 |
Engine Detail | |
| Kubota V2403-M-T | |
| turbocharged diesel | |
| 4-cylinder | |
| liquid-cooled | |
| Displacement: | 148.6 ci 2.4 L |
| Emissions: | Interim Tier IV |
| Emission control: | EGR |
| Power (gross): | 52.2 hp 38.9 kW |
| Air cleaner: | dual dry element |
| Rated RPM: | 2700 |
| Starter: | electric |
| Starter volts: | 12 |
| Oil capacity: | 8 qts 7.6 L |
| Coolant capacity: | 7.9 qts 7.5 L |
Dimensions | |
| Wheelbase: | 74.6 inches 189 cm |
| Length: | 127.8 inches 324 cm (2WD) |
| 122.8 inches 311 cm (4WD) | |
| Width: | 69.7 inches 177 cm |
| Height (ROPS): | 95.7 inches 243 cm |
| Ground clearance: | 15.9 inches 40 cm (2WD) |
| 15.2 inches 38 cm (4WD) | |
| Front tread: | 50.4 to 62.2 inches 128 to 157 cm (2WD) |
| Front tread: | 52.5 to 52.2 inches 133 to 132 cm |
| Rear tread: | 54.1 to 58.7 inches 137 to 149 cm |
