New Holland T4.75
Type: Utility Tractors
Contents:
Production | |
| Manufacturer: | New Holland |
| Type: | Utility tractor |
New Holland T4.75 Power | |
| Engine (gross): | 74 hp 55.2 kW |
| PTO (claimed): | 65 hp 48.5 kW |
Mechanical | |
| Chassis: | 4x2 2WD |
| 4x4 MFWD 4WD | |
| Differential lock: | mechanical differential lock |
| Steering: | hydrostatic power |
| Brakes: | hydraulic wet disc |
| Cab: | Two-post foldable ROPS. Optional cab with air-conditioning. |
| Transmissions: | 8-speed partially synchronized mechanical shuttle |
| 8-speed power shuttle | |
| 12-speed mechanical shuttle | |
| 12-speed power shuttle | |
Hydraulics | |
| Type: | open center |
| Rear valves: | 1 or 2 |
| Mid valves: | 0 or 2 |
| Pump flow: | 12.5 gpm 47.3 lpm |
| Total flow: | 19.8 gpm 74.9 lpm |
| Steering flow: | 7.3 gpm 27.6 lpm |
| 9.5 gpm 36.0 lpm (power shuttle) | |
Tractor hitch | |
| Rear Type: | 2/1 |
| Control: | mechanical upper-link draft sensing |
| Rear lift (at 24"/610mm): | 3,664 lbs 1661 kg |
Power Take-off (PTO) | |
| Rear PTO: | independent |
| Clutch: | mechanical dry disc, wet disc with power shuttle |
| Rear RPM: | 540 (1.375) |
| 540/540E | |
| Engine RPM: | 540@2160 540E@1592 |
Electrical | |
| Ground: | negative |
| Charging system: | alternator |
| Charging amps: | 120 |
| Battery CCA: | 730 (ROPS) |
| 800 (cab) | |
| Battery volts: | 12 |
Engine Detail | |
| FPT F5C | |
| turbocharged diesel | |
| 4-cylinder | |
| liquid-cooled | |
| Displacement: | 195 ci 3.2 L |
| Bore/Stroke: | 3.898x4.094 inches 99 x 104 mm |
| Emissions: | Tier 3 |
| Power (gross): | 74 hp 55.2 kW |
| Air cleaner: | dry |
| Pre-heating: | grid heater |
| Rated RPM: | 2300 |
| Starter: | electric |
| Starter volts: | 12 |
Dimensions | |
| 2WD Wheelbase: | 83.3 inches 211 cm |
| 4WD Wheelbase: | 82.8 inches 210 cm |
| Length: | 149.3 inches 379 cm |
| Height (ROPS): | 78.9 inches 200 cm |
| Height (cab): | 97.8 inches 248 cm |
| Rear axle: | Flange |
| 2WD Front tread: | 60.2 to 79.9 inches 152 to 202 cm |
| 4WD Front tread: | 60.8 to 76.6 inches 154 to 194 cm |
| Rear tread: | 52.2 to 76 inches 132 to 193 cm |
